DC133
Digital Visualizer
User manual
English - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC133 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lumens DC133

  • Page 1 DC133 Digital Visualizer User manual English - 1...
  • Page 2: Table Of Contents

    Table of Contents COPYRIGHT INFORMATION ................4 CHAPTER 1 PRECAUTIONS ................5 CHAPTER 2 PACKAGE CONTENT ..............7 CHAPTER 3 PRODUCT OVERVIEW ..............8 ..............8 RODUCT NTRODUCTION I/O C ................. 9 ONNECTION DIP S ..................9 WITCH ................10 EMOTE ONTROL CHAPTER 4 HOW TO USE IT ................
  • Page 3 OSD M ..................17 CHAPTER 6 TROUBLESHOOTING..............20 English - 3...
  • Page 4: Copyright Information

    Lumens Digital Optics Inc. is in process the trademark registration of Lumens. No part of this document may be copied, reproduced, or transmitted by any means, without prior written permission from Lumens Digital Optics Inc. Except documentation kept by the purchaser for backup purposes.
  • Page 5: Chapter 1 Precautions

    Chapter 1 Precautions Always follow these safety instructions when setting up and using the Digital Visualizer: Do not place the Digital Visualizer on an unstable trolley, stand or table. Do not use the Digital Visualizer near water or source of heat. Use attachments only as recommended.
  • Page 6: Safety Precautions

    water. Safety Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. This Digital Visualizer has a 2 wires AC line Plug. This is a safety feature to ensure that the plug will fit into the power outlet.
  • Page 7: Chapter 2 Package Content

    Chapter 2 Package Content Please make sure the package comes with the following items when you unpack: items) Main Unit Quick Start Guide User’s Manual Power Cable VGA Cable USB Cable Remote C-Video Cable Soft Bag (Big) Soft Bag (Small) English - 7...
  • Page 8: Chapter 3 Product Overview

    Chapter 3 Product Overview Product Introduction Gooseneck Lens Lamp I/O Port Power/Control keypad Infrared rays area DIP Switch English - 8...
  • Page 9: I/O Connection

    I/O Connection 3.3 DIP Switch The default settings are listed below! AE ON C-Video SVGA (Default) AE OFF NTSC (OFF at all time) English - 9...
  • Page 10: Remote Control

    Remote Control Power: Zoom +/-: Turn on/ off. Make the image larger & smaller Play/Del: Capture: Recall/Delete the saved Capture the image Freeze: images in the flash memory of your Digital Visualizer. Freeze the image AWB: 10. Flip: Auto white balance Rotate the image by 180 degrees Menu: 11.
  • Page 11: Chapter 4 How To Use It

    Chapter 4 How to use it 4.1 Getting Started 4.1.1 Turn on the Digital Visualizer Remote Keypad 4.1.2 Lens focus Turn the lens to optimize the focus 4.1.3 Zoom in / Out Press the control button on the remote controller English - 11...
  • Page 12: General Functions

    4.2 General Functions 4.2.1 Switch source Press 『Source』 to change the image source from PC. The default setting is Digital Visualizer. Remote Keypad Monitor Notebook Projector 4.2.2 Photo/Text The default setting is『Photo』. Choose『Text』for displaying text file. Remote English - 12...
  • Page 13: Zoom In / Out

    4.2.3 Zoom in / Out 4.2.4 Adjust Brightness 4.2.5 OSD Menu English - 13...
  • Page 14: Osd Function Select

    4.2.6 OSD Function Select Remote Keypad 1. Press 『^ v< >』 to search functions. 2. Press the Enter key to enable your selection. 4.3 Advanced 4.3.1 Capturing Image Remote:Press『Capture』to capture the image you want. Control Panel: 1. Press『Menu』to access OSD menu. 2.
  • Page 15: Delete Images

    3. Press『Enter』to display the image with full screen. 4. Press『 』to view next image. 5. Press『Play』to go back. 6. Press『Menu』to exit. Control Panel: 1. Press『Menu』to access OSD menu. 2. Press『 』to choose (Storage) and press『Enter』to execute. 3. Press『 』to choose『Play』 4.
  • Page 16 6. Press『Enter』to display the image with full screen. 7. Press『Menu』to access OSD menu. 8. Press『 』to choose (Storage) and press『Enter』to execute. 9. Press『 』to choose『Delete』 10. Press『Enter』to execute image deleting. 11. Double click『Menu』to exit. English - 16...
  • Page 17: Chapter 5 Osd Menu Introduction

    Chapter 5 OSD Menu Introduction 5.1 Operation Menu Remote Control and Display Panel: 1. Press『Menu』to access OSD menu. 2. Press『 』to select the function that you want. 3. Press『Enter』to execute. 4. Double click『Menu』to exit the OSD menu. 5.2 OSD Menu There are four layers for OSD menu –...
  • Page 18 Brightness 0-46 (for PAL) Brightness adjustment 0-40 ( for NTSC) Display Digital Zoom Zoom Adjust Zoom 100% ~ 1600%. Gamma Photo / Text Select Photo/Text Mode. Image Normal / Gray / Film Select Normal/Gray/Film Mode. Flip On/Off Adjust the image up and down by 180°.
  • Page 19 C-Video Mode Layer 1 Layer 2 Layer 3 Function Brightness 0-46 (for PAL) Brightness adjustment 0-40 ( for NTSC) Gamma Photo/Text Select Photo/Text Mode. Display Image Normal/Gray Select Normal/Gray Mode. Use Freeze to retain the image on Freeze On/Off the screen. Exit Exit this menu.
  • Page 20 Solution – Adjust the Control Button on the Digital Visualizer. The updated information will be regularly released on Lumens web site, please visit our web site http://www.lumens.com.tw for the latest information. English - 20...
