You cannot change any of the values on this page. To update this page and to show the current
attached devices, click the Refresh button.

4.7.3 Address Reservation

Choose menu "DHCP→Address Reservation", you can view and add a reserved addresses for
clients via the next screen (shown in Figure 4-21).When you specify a reserved IP address for a
PC on the LAN, that PC will always receive the same IP address each time when it accesses the
DHCP server. Reserved IP addresses should be assigned to the servers that require permanent
IP settings.
MAC Address - The MAC address of the PC of which you want to reserve IP address.
Assigned IP Address - The IP address of the router reserved.
Status - The status of this entry either Enabled or Disabled.
To Reserve IP addresses:
1.
Click the Add New button. (Pop-up Figure 4-22)
2.
Enter the MAC address (in XX-XX-XX-XX-XX-XX format.) and IP address in dotted-decimal
notation of the computer you wish to add.
3.
Click the Save button when finished.
To modify or delete an existing entry:
1.
Click the Modify in the entry you want to modify. If you want to delete the entry, click the
TL-WR841N/TL-WR841ND
Figure 4-21 Address Reservation
Figure 4-22 Add or Modify an Address Reservation Entry
37
Wireless N Router
