Connection Guide

TL-WR841N to May's Hotspot Service fixed wireless service.

Step 1

Choose your connection type (Wired or Wireless)

Step 1a: If Wireless, connect to your TP-Link wireless network. Find the wireless network (named

TP-LINK_xxxxxx by default which is printed on the label of the router) from the Wi-Fi list on your

device and connect it with the wireless password (default password is printed on the router's label

as well).

Step 1b: If Wired, connect your Ethernet cable to one of the LAN ports on the back of your TP-Link

router.

Page 1 TP-LINK_xxxxxx by default which is printed on the label of the router) from the Wi-Fi list on your device and connect it with the wireless password (default password is printed on the router's label as well). Step 1b: If Wired, connect your Ethernet cable to one of the LAN ports on the back of your TP-Link router.
Page 2 Connection Guide TL-WR841N to May’s Hotspot Service fixed wireless service. Step 2 Open a web browser (i.e Safari, Google Chrome or Internet Explorer). At the top of the window in admin the address bar, type in http://tplinkwifi.net enter username and password (default for both) then Click Login.
Page 3 Connection Guide TL-WR841N to May’s Hotspot Service fixed wireless service. Step 3 Configure WAN Connection Type On the router’s management page, click Network > WAN on the left of the web page: Change the WAN Connection Type to PPPoE. Step 4 Enter your PPPoE username and password which are provided by May’s Hotspot.
Page 4 Connection Guide TL-WR841N to May’s Hotspot Service fixed wireless service. Step 6 Wait for a few minutes and check that the status led changes to green from orange (similar as below). That means the connection between the Router and the Modem has been established.
