TP-Link TL-WR841N Quick Installation Manual

Quick Installation Guide
Wireless N Router
Note: TL-WR841N is used for demonstration in this guide.
Images may differ from actual products.
If your internet comes from an Ethernet outlet,
connect the router's WAN port to it, then skip
steps 1, 2, and 3.
Configure the router
1. Connect your computer to the router (Wired or Wireless)
Wired
Turn off the Wi-Fi on your computer and connect it to the router
via an Ethernet cable.
Wireless
A. Find the product label at
the bottom of the router.
B. Use the default network
name (SSID) and password
to join the network.
Tip: If you are using a smartphone or
tablet, you can also scan the QR code
to join the preset network directly.
Power adapter
2. Launch a web browser, and enter http://tplinkwifi.net or
http://192.168.0.1 in the address bar. Create a password
to log in.
Note: If the login window does not appear, please refer to FAQ > Q1.
QR
Wireless Password/PIN:
Code
XXXXXXXX
SSID:TP-Link_XXXX
POWER WAN Router
Connect the powered-off modem to the
router's WAN port via an Ethernet cable.
Connect the power adapter to the router.
http://tplinkwifi.net
Password
Confirm Password
Start
Important
Unplug the modem, and remove
the backup battery if it has one.
Modem
Power on the modem, then wait
about 2 minutes for it to restart.
Verify that the router's
turns solid on before continuing.
3. Click Next to start the Quick Setup. Select Wireless Router and
follow the step-by-step instructions to set up the internet
connection.
Note: If you are not sure of the WAN Connection Type, please click Auto-Detect.
Tether App
The TP-Link Tether app provides a simple, intuitive way to access and
manage your router. Scan the QR code to download Tether from the Apple
App Store or Google Play.
LED
