Quick Start Guide
Diva-Lite LED 20U/30U
®
(True Match Firmware 5.0)
(RDM)
Part No. 3100119 Rev B
05-01-2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the DIV-LX20U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kino Flo DIV-LX20U

Summary of Contents for Kino Flo DIV-LX20U

  • Page 1 Quick Start Guide Diva-Lite LED 20U/30U ® (True Match Firmware 5.0) (RDM) Part No. 3100119 Rev B 05-01-2021...
  • Page 2 Diva-Lite LED DMX Fixture DIV-LX20U Diva-Lite 20 LED DMX, Univ DIV-LX30U Diva-Lite 30 LED DMX, Univ Included w/ Diva-Lite LED Models LVR-SL290-P Diva-Lite 20 Louver/HP, 90° (Included) LVR-SL390-P Diva-Lite 30 Louver/HP, 90° (Included) MTP-LBC Kino 41 Lollipop w/ Baby Receiver Curve (16mm)
  • Page 3 Diva-Lite 20 LED DMX Kits KIT-DL20XBU Diva-Lite 20 LED DMX Kit, Univ w/ Soft Case Kit Contents: Dimensions: 1 Diva-Lite 20 LED Fixture 31 x 7.5 x 18” 1 Soft Case (79 x 19 x 46cm) Weight: Diva-Lite 20 LED 19.5 lb DMX Kit w/ Soft Case (9kg)
  • Page 4 Diva-Lite 30 LED DMX Kits KIT-DL30XBU Diva-Lite 30 LED DMX Kit, Univ w/ Soft Case Kit Contents: Dimensions: 1 Diva-Lite 30 LED Fixture 42.5 x 7.5 x 16.5” 1 Soft Case (108 x 19 x 42cm) Diva-Lite 30 LED Weight: DMX Kit w/ Soft Case 23 lb (10kg)
  • Page 5 Power AC Input The Diva-Lite LED includes a built-in power supply with universal input from 100-240VAC. It also includes a 12ft power cord with a locking IEC connector. Ambient Operating Temperature The Diva-Lite LED is designed to operate at temperatures from 14°F to 104°F (-10°C to 40°C).
  • Page 6 Control Panel - White Mode A) On /Off: On = Green light displayed. Off = Red light displayed. The display and all menu settings can be operated while the power button is in the Off position, as long as power is applied to the controller. The On /Off button only controls the light source.
  • Page 7 Control Panel - Gels/Hue Mode Gels/Hue Mode A) Menu: Provides access to menu options such as General settings (Gels/Hue Mode), Reset, DMX, DMX Wireless, Camera LUT and Color Space. Shortcut: While on control screen, press and hold for 3 seconds to switch through menus (White, Gels &...

  • Page 8: Rgb Mode

    Control Panel - RGB Mode RGB Mode A) Menu: Provides access to menu options such as General settings (RGB Mode), Reset, DMX, DMX Wireless, Camera LUT and Color Space. Shortcut: While on control screen, press and hold for 3 seconds to switch through menus (White, Gels &...
  • Page 9 Control Panel - CIE xy CIE xy Mode A) Menu: Provides access to menu options such as General settings (CIE xy mode), Reset, DMX, DMX Wireless, Camera LUT and Color Space. Shortcut: While on control screen, press and hold or 3 seconds to switch through menus (White, Gels &...
  • Page 10 Control Panel - FX (Effects) FX (Effects) Mode FX mode provides access to effects including Candle, Fire, TV, Police, Lightning, Paparazzi, Pulse and Scroll. Candle mode used as an example: A) FX Option: Choose the desired FX Mode by rotating the control knob. When on the desired effect, there will be several pre-programed effects as well as control parameters that can be altered.
  • Page 11 The camera code (C1 for Arri Alexa), for example, will appear on the main menu between DIM and CCT to designate that a camera setting is active. Note: When the controller is reset, the camera settings will go to Kino Flo Default mode.

  • Page 12: Color Space

    Color Space Color Space defines the RGB color space used and only affects color – not Kelvin. It is used in RGB mode and Hue Angle and Saturation. There are a few instances in the FX (Effects) mode that are also affected when color is used. The RGB color space defines the value of Red, Green, and Blue primaries (in CIE xy) and the white point is fixed at 6500 Kelvin.
  • Page 13 Diva-Lite LED Fixture Specifications DIV-L20XU Diva-Lite 20 LED DMX, Univ AC Input Voltage: 100~240VAC 50/60Hz, 150W Amperage VAC: 1.25A at 120VAC, 0.65A at 230VAC DC Input Voltage: 18~36VDC, 150W Amperage VDC: 6.25A at 24VDC Kelvin Range: 2500K~9900K Diva-Lite LED 20 Dimming Range: 100%~1% Weight: 14.5 lb (6.5kg) Dimensions: 25 x 13 x 6”...
  • Page 14 This product is made of recyclable materials and should be disposed of in accordance with governmental regulations. Kino Flo, Inc. 2840 N. Hollywood Way, Burbank, CA 91505, USA Tel: 818 767-6528 website: www.kinoflo.com...
