• DT - The month day and year in the format that has been configured in the
AUDIT TRAIL PRINTER PARAMETERS screen will be sprayed.
• TI - The hour minute and second in the format that has been configured in
the AUDIT TRAIL PRINTER PARAMETERS screen will be sprayed.
• SN - A five-digit physical count of all envelopes that have been printed on
will be sprayed. It is updated on every envelope sprayed. This value will
start at zero and count up to 65,535 before wrapping to zero.
• < > - When selected, a character space is entered.
• NL - When selected, a new line is entered. Doing so will cause all following
element selections to be sprayed on the next line.
3.6.3.2. Barcode 1 (B1) Details
A unique, 11-digit Postnet is sprayed based on the time/day that is set in the
RTC (real-time clock) chip in the machine. The 11 digits in the barcode reflect
the following information:
Table 4: Barcode digit information
Y - year represented by the least significant digit (limit of wrapping
1
decade)
2-4 DOY - Day of year, a 3 digit number from 1-366
SOD - second of the day, a 5 digit number from 1-86,400 (24 X 60 X
5-9
60)
UU - Number representing piece processed within the last second,
10-11 should range from 1-14 (2 digits needed because 50,000/3,600 =
13.8888)
The above can be described as:
Total digits
Position in barcode
Meaning
Operation
Omation® Model 306™ Envelopener® Operator Manual
11
1 234 56789 01
Y DOY SOD UU
