Opex Omation 206 Operator's Manual

Options

Automatic Batch Count

(for machines with optional batch count capability only).
Press the Start button and allow the 206 to boot up. If the 206
is already turned on, press and hold the cancel button until
the screen with [RUN ZERO COUNT PARAMETERS] is
displayed. Press the left or right arrow to select Parameters.
Press Enter. The Select Job Option screen will appear which
will allow for several options.
Select Job Options
Batcher Count Batcher Delay
Conveyor On Time Batcher Re-Start
Feed Re-Start
Use the arrow keys on the keypad to highlight Batcher Count,
then press Enter. The Batch Count screen will appear. Once
again use the arrow keys to highlight and change the number
of pieces desired in each batch.
Batch Count = 0000
(Set count to zero to turn off batcher.)
Use Arrows to change value. Press Enter to SAVE
or CANCEL to exit.
After setting the amount desired in the batch press Cancel to
Exit.
It is now possible to set the time delay between batches. Use
the arrow keys to choose Batcher Delay. Press Enter again
and set the delay time between batches. Use the arrow keys to
change the delay setting.
Shorter → Longer
1......2......3......4......5......6......7......8......9......10
Press Cancel to return to the Select Job Option screen. Use
the arrow keys to select Batch Re-Start.
Batch Re-Start
Manul Resume Auto Resume

Machine Settings

Conveyor on Time
From the Select Job Options screen use the arrow keys to
highlight Conveyor On time. Press Enter. This machine setting
allows the lower conveyor belt to run longer or shorter after the
last piece of mail has been opened. It is especially useful when
running batches and larger amounts of mail.
Feed Mode
From the Select Job Options screen use the arrow keys to
highlight Feed Re-Start. Press Enter. This machine setting
enables or disables the automatic start and stop of the 206.
The 206 Running.
Opened Mail Piece.

Specifications

Length: 1194cm
Depth: 572cm
Height: 1448cm
Weight: 110Kg
Power: 220-240 VAC, 50Hz, 3 Amps.
Speed: 600 Envelopes per minute
Envelopes Supported: All Main Envelope Sizes
Thickness: Up to 13mm
Depth of Cut: From no cut to 3mm
Noise Level: <85 dBA
It is certified that the system complies with all
applicable Directives of the European Union.
Please note that when running at sound levels over 80dBA
(First Action Level), operator hearing protection must be
provided.
Opex Omation 206
Letter Opener
Operator Guide
