- Page 1 © 2023 Order #XXXXX MOD-1529 Reception Counter Back View Front View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
-
Page 2: General Setup Instructions
© 2023 Order #XXXXX General Information General Setup Instructions - Read entire setup instruction manual prior to WARNING unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly. -
Page 3: Back View
© 2023 Order #XXXXX Counter Assembly Item Qty. Description Steps: 37.5”h S44 Vertical Extrusion 1) Connect lower horizontals [5,6,7] between verticals [1,2,3,4]. 37.5”h S44 Vertical Extrusion 2) Attach vertical [8] to lower horizontal [6]. 37.5”h S44 Vertical Extrusion 3) Slide Infills between verticals [1,2] and [3,4]. - Page 4 © 2023 Order #XXXXX Aero Frame Assembly Using Your Setup Instructions The Aero Setup Instructions are created specifically for your configuration. The instructions include an exploded view of the frame which is sequentially labeled. We encourage you to review the instructions before attempting to assemble your exhibit.
-
Page 5: Completed Assembly
© 2023 Order #XXXXX Counter Assembly (cont’d) Item Qty. Description Steps: 9/9A 15.28” TSP46 Curved Extrusion 1) Connect extrusions [9,9A,10,10A,11,11A] together. See TSP46 Corner Connection detail. 10/10A 30.382”w TSP46 Horizontal Extrusion 3) Slide Aero frame assemblies into the groove of front verticals [2,3]. 11/11A 30.382”w TSP46 Horizontal Extrusion 4) Place counter top on top of assembled base.
