Summary of Contents for Classic Exhibits gravitee GK-1012
- Page 1 © 2019 Order #XXXXX GK-1012 General Layout 10’ 10’ Top View Perspective View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
- Page 2 © 2019 Order #XXXXX GK-1012 Grid View = 1 sq foot...
-
Page 3: Side-By-Side
© 2019 Order #XXXXX General Information General Setup Instructions Assembly Assembly Cont’d - Read entire setup instruction manual prior to Push pin lock into hole of connecting frame. unpacking parts and pieces. Note: Block on pin lock will secure in groove. - The setup instructions are created specifically for this configuration. - Page 4 © 2019 Order #XXXXX CEI110 Frame Assembly Corner Connection Corner Bracket Assembly 1) Slide TWO-PIECE TS RV 2 L-bracket into Upper Interior Center Slot of extrusion so that two Horizontal set screws are inside groove. Tighten two set screws to secure. Upper Slide verticals over Horizontal...
- Page 5 © 2019 Order #XXXXX Crate Packing Crate 1 of 1...
-
Page 6: Completed Assembly
© 2019 Order #XXXXX GK-2012 Lightbox Assembly Item Qty. Description 76” CEI110 Horizontal Extrusion 76” CEI110 Horizontal Extrusion 95” CEI110 Vertical Extrusion 95” CEI110 Vertical Extrusion Power Break Steps: 1) Assemble extrusions flat on floor. See CEI152 Frame Assembly sheet. 2) Connect light cords and attach transformers. - Page 7 © 2019 Order #XXXXX GK-2012 Backwall Assembly Item Qty. Description Base Plate 11.5”w x 95”h Gravitee Panel 94.5” Gravitee Corner Connector w/ Caps 38”w x 95”h Gravitee Panel w/ (2) 91.904“ S44 94.5” Gravitee Corner Connector w/ Caps w/Caps 11.5”w x 95”h Gravitee Panel w/Caps 95”...
- Page 8 © 2019 Order #XXXXX MOD-1700 Cabinet with USB Ports Steps: 1) Connect light blocker to Velcro on interior of assembled frame. 2) Attach assembled frame to verticals [3] and [3A]. Frame Attachment detail. 3) Install SEG graphic to front of assembled frame. SEG Graphic Installation detail.
-
Page 9: Frame Assembly
© 2019 Order #XXXXX MOD-1700 Cabinet with USB (Cont’d) Item Qty. Description Steps: 1,1A 46.25” CEI-110 Horizontal Extrusion 1) Assemble frame extrusions [1] [1A] [2] and [2A]. See CEI152 Frame Assembly sheet. 2,2A 37.5” CEI-110 Vertical Extrusion 2) Connect lights and transformer. See Light to Light Connection Light to Transformer Connection details.
