Dual Ultrawide Vertical Monitor Desk Stand
Instruction Manual
SKU: STAND-V200L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v200l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V200L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-V200L

  • Page 1 Dual Ultrawide Vertical Monitor Desk Stand Instruction Manual SKU: STAND-V200L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v200l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Install Lower Pole (D) to Base (C) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Remove protective film from Pads (H) and apply them to Base (C) as shown. STEP 2 Slide Pole Cable Clip (G) and one VESA Bracket (B) onto Lower Pole (D). Adjust the height location of VESA Bracket (B) and tighten using the 6mm Allen Wrench (T-B).
  • Page 4 STEP 3 Press Pole Cap (F) into Upper Pole (E), using the side without internal threading . STEP 4 Screw Upper Pole (E) onto Lower Pole (D). Slide remaining Cable Clip (G) and VESA Bracket (B) onto Upper Pole (E). Adjust the height location of VESA Bracket (B) and tighten using the 6mm Allen Wrench (T-B).
  • Page 5 STEP 5 Mount VESA Plates (A) to monitors using appropriate Screws (M-A thru M-D), M8 Washers (M-E), and Spacers (M-F). STEP 6 Slide monitors with VESA Plates onto VESA Brackets (B) and secure using M6x10mm Thumbscrew (S-B).
  • Page 6 STEP 7 Use Cable Clips (G) to route cables. Store Allen Wrenches (T-A, T-B) in slots of Clips. WARNING Always keep monitors positioned over the desktop within the arrow range shown.
  • Page 7 ADJUST AS DESIRED Use 6mm Allen Wrench (T-B) to loosen or tighten Monitor Bracket (B) tension.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
