Pneumatic Arm Dual Ultrawide Monitor Desk Mount
Instruction Manual
SKU: STAND-V202Q
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v202q
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V202Q
Summary of Contents for Vivo STAND-V202Q
- Page 1 Pneumatic Arm Dual Ultrawide Monitor Desk Mount Instruction Manual SKU: STAND-V202Q Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v202q GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 DO NOT EXCEED WEIGHT CAPACITY. 2.2-30.9lbs Failure to do so may result in serious injury. (1-14kg) PER ARM ASSEMBLY STEPS STEP 1 (Option A) Clamp Installation Secure Upper Clamp (E) to the underside of Base (D) using M6x10mm Flathead Screws (S-B) and 4mm Allen Wrench (T-B).
- Page 4 STEP 1 (Option B) Grommet Installation Insert Carriage Bolt (S-A) into Grommet Plate (H) and secure to underside of Base (D) using M6x10mm Flathead Screws (S-B) and 4mm Allen Wrench (T-B). Peel back adhesive backing and apply Pads (K) to underside of Base (D). Place base assembly over grommet hole in desktop and place Support Plate (I) and Knob (J) on the end of Carriage Bolt (S-A).
- Page 5 STEP 2 Place Lower Arms (B) onto Base (D) and secure by tightening set screws with 3mm Allen Wrench (T-A). Install Upper Arms (A) on Lower Arms (B) and tighten set screws with 3mm Allen Wrench (T-A) to secure. STEP 3 Secure VESA Plates (C) to back of monitors using appropriate Screws (M-A thru M-D), M6 Washers (M-E), and 6mm Allen Wrench (T-C).
- Page 6 STEP 4 Place monitors with VESA Plates (C) onto Upper Arms (A) and secure with M6x12mm Thumbscrews (S-C). STEP 5 While holding Upper Arm (A) in the horizontal position, adjust the gas spring tension using 6mm Allen Wrench (T-C). Adjusting Tension Decrease Strength - If the arm raises up, turn the adjustment screws clockwise until it holds the...
- Page 7 Cable Management Covers Lower Arm (B): Upper Arm (A): 1. Slide covers forward to remove. 1. Pull tabs outward on lower portion of covers. 2. Place cables in covers. 2. Pull upper tabs outward to fully remove covers. 3. Connect inner tabs to clips on arm to 3.
- Page 8 - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
