Mechanical Arm Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V200S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v200s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V200S and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V200S

  • Page 1 Mechanical Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V200S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v200s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 4.4-15.4lbs Failure to do so may result in serious injury. (2-7kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Desk Clamp Installation Assemble base (B) to clamp (C) using M6x8 bolts (E), and tighten with 5mm Allen wrench (G). Unscrew the large clamp bolts to the “open”...
  • Page 4 STEP 2 While holding the arms (A) in the closed position, cut the shipping tie from each arm. 1. Firmly hold the two halves of the spring arm together and have another person cut off the cable tie from around the spring arm. 2.
  • Page 5 STEP 5 Align bolts installed to monitors with VESA plate. Secure using two more bolts (M-A or M-B) and washers (M-C) in the bottom two holes. Tighten all four bolts with a Phillips screwdriver. STEP 6 If the arms (A) are not able to maintain a lowered position, tighten bolts on the side of each arm using the 5mm Allen wrench (G).
  • Page 6 STEP 7 Tighten or loosen the tilt joint using the 5mm Allen wrench (G). Adjust the monitor positions as desired.
