- Page 1 Mechanical Arm Dual Ultrawide Monitor Desk Mount SKU: STAND-V200E Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-v200e...
- Page 2 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
- Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 4 Package Contents A (x1) B (x2) C (x2) D (x2) Base Lower Arm Spring Arm VESA Adapter E (x1) F (x1) G (x1) Clamp Brace Clamp Clamp Plate Included Hardware & Tools S-A (x2) S-B (x4) S-C (x2) S-D (x2) M-A (x8) M8 Nut M6x12mm Screw...
- Page 5 ASSEMBLY STEPS STEP 1 Option 1: Clamp Assembly Desktop Thickness: 3/8” to 2” (10 - 50mm) or 1.5” to 3” (40 - 80mm) Attach Clamp Brace (E) to Base (A) using M6x12mm Screws (S-B) and tighten with 4mm Allen Wrench (T-A). Thread M10x63mm Screws (S-D) into Clamp (F) and place Clamp Plate (G) on top.
- Page 6 Option 1 - Clamp [Cont’d] Loosen bolts on back of Clamp (F) using 4mm Allen Wrench (T-A), leaving 6mm of thread exposed. Hang assembled clamp onto Clamp Brace (E), using guide below to determine location based on desktop thickness. Top Holes Lower Holes 3/8”...
- Page 7 Option 2: Grommet Mount Assembly Desktop Thickness: 3/8” to 1 (10-35mm) 3/8” Insert M10x63mm Screws (S-D) through Clamp Plate (G). Place Base (A) over desktop grommet holes and insert M10x63 Screws through hole and tighten to Base using the 6mm Allen Wrench (T-B). No Grommet Hole? If you do not have an existing grommet holes for installation, drill two holes through desktop in your desired mounting location using a 3/8”...
- Page 8 STEP 2 ** READ BEFORE PROCEEDING** The Monitor Arms can be assembled to have a Full 360° Eotation or a Limited 180° Rotation. Follow Rotation Instructions below, then pick the rotation option that fits your setup needs. ±180° (360°) ±90° (180°) Full Rotation Limited Rotation Locating Rotation Adjustment Screw...
- Page 9 ±180° (360°) ±90° (180°) Full Rotation Limited Rotation Fully tighten both Adjustment Screws using Loosen both Adjustment Screws using the the flat end on 4mm Allen Wrench (T-A). flat end on 4mm Allen Wrench (T-A). The screw should stick out 3/16” [4mm]. STEP 3 Slide Lower Arms (B) onto Base (A) and tighten the Set Screws on the back of both Arms using the flat end of 4mm Allen Wrench (T-A)
- Page 10 STEP 4 Place Spring Arms (C) on top of Lower Arms (B), and secure by turning the set screw in back with 4mm Allen Wrench (T-A). STEP 5 Attach VESA Adapters (D) using M8x35mm Screws (S-C) and M8 Nuts (S-A) on as Spring Arms (C) using 6mm Allen Wrench (T-B).
- Page 11 STEP 6 Unscrew Thumbscrews (D1) on VESA Adapters (D) and remove VESA Plates (D2). VESA Plate (D2) Install the VESA Plates (D2) to monitors using M4x12mm Screws (M-A) or M5x12mm Screws (M-B) with M5 Washers (M-C), making sure the arrow in back is pointing up.
- Page 12 STEP 7 Adjusting the Tilt Joint Adjustment Screw Loosen Tilt Joint: Lock Angle Use 6mm Allen Wrench (T-B) to Tighten as much as possible loosen the tilt joint Adjustment using the 6mm Allen Wrench Screw, located on the side of (T-B) to lock the angle.
- Page 13 STEP 8 VESA Plate (D2) With the assistance of a second person, line up the on your monitor with the VESA Bracket (D) and the Plate Hooks into the pockets of the VESA Bracket. 2 Person Mounting is Recommended *Monitor & VESA Bracket may need to be angled backwards slightly when sliding on.
- Page 14 Fine Tune Tilt Angle If the monitor is angled further than intended... Heavy Weighted/ Ultrawide Monitors [ 22lbs - 44lbs ] Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the tilt joint...
- Page 15 STEP 9 Adjusting Monitor Height Position Mount Arm Turn 10-20x to Set Monitor Height Position the arm horizontally, as shown above, and firmly hold in Turn 6mm Allen Wrench (T-B) 10-20 times place. to obtain proper support for your monitor. Use the guide below to adjust the tension according to the amount of counterbalance Insert 6mm Allen Wrench (T-B)
- Page 16 STEP 10 Remove cable covers on Spring Arms (C) by pulling the sides away from the arm to unclip them. Slide cable covers on Lower Arms (B) forward to remove them. Manage cables in cable covers and re-install.
- Page 17 Adjust as Desired Adjust swivel using 6mm Allen Wrench (T-B).
- Page 18 WARNING Ensure the display is alway positioned over the desk surface to prevent damage.
- Page 19 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
- Page 20 LAST UPDATED: 08/12/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
