- Page 1 Dual Ultrawide Vertical Monitor Desk Mount STAND-V200R Assembly Manual...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
- Page 3 Package Contents A (x2) B (x2) D (x1) C (x1) VESA Plate VESA Bracket Lower Pole Clamp E (x1) F (x1) G (x2) H (x1) Upper Pole Pole Cap Cable Clip Grommet Plate I (x5) J (x1) Support Plate Included Hardware & Tools S-A (x3) S-B (x2) M-A (x8)
-
Page 4: Assembly Steps
Assembly Steps STEP 1 Option 1: Clamp Installation Install Lower Pole (D) to Clamp (C) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Remove protective film from Pads (I) and apply them to Clamp as shown. Tighten the Clamp (C) onto the desktop. 10-85mm Proceed to STEP 2 on Page 6... - Page 5 Option 2: Grommet Installation Remove protective film from Pads (I) Use a Phillips screwdriver to remove the Screw (C1) from the Clamp Bolt (C2) and remove the and apply them to the bottom side of Clamp Bolt from Clamp (C). Grommet Plate (H).
- Page 6 STEP 2 Slide Pole Cable Clip (G) and one VESA Bracket (B) onto Lower Pole (D). Adjust the height location of VESA Bracket and tighten using 6mm Allen Wrench (T-B). STEP 3 Press Pole Cap (F) into Upper Pole (E) on the side without internal threading.
- Page 7 STEP 4 Thread Upper Pole (E) onto Lower Pole (D). Slide remaining Cable Clip (G) and VESA Bracket (B) onto Upper Pole. Adjust the height location of VESA Bracket (B) and tighten using the 6mm Allen Wrench (T-B).
- Page 8 STEP 5 Mount VESA Plates (A) to monitors using appropriate Screws (M-A thru M-D) with M8 Washers (M-E). If your monitor’s VESA pattern is recessed use Spacers (M-F). Ensure the Lip on VESA Plate is on the top. Too Long Too Short...
- Page 9 STEP 6 Slide monitors with VESA Plates (A) onto VESA Brackets (B) and secure using M6x10mm Thumbscrew (S-B). 2 Person Mounting Recommended...
-
Page 10: Tilt Adjustment
Tilt Adjustment Standard Monitors Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the tilt joint Adjustment Screw, located behind VESA Plate (A). - Page 11 STEP 7 Use Cable Clips (G) to route cables. Store Allen Wrenches (T-A, T-B) in slots of Clips. Swing and rotate as desired. **WARNING** Always keep monitors positioned over the desktop within the arrow range shown.
