If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Page 4
Package Contents A (x2) B (x1) C (x1) VESA Bracket Clamp Lower Pole D (x1) E (x1) Upper Pole Support Plate F (x1) G (x2) H (x1) I (x5) Pole Cap Pole Cable Clip Grommet Plate Included Hardware & Tools S-A (x3) M-A (x8) M-B (x8)
Page 5
ASSEMBLY STEPS STEP 1a Assembly Option #1 - Desk Clamp Install Lower Pole (C) to Clamp (B) using M6x16mm Screws (S-A) and 4mm Allen Wrench (T-A). Remove protective film from Pads (I) and apply them to Clamp (B) as shown. Secure clamp assembly to desktop by tightening hand bolt.
Page 6
STEP 1b Assembly Option #2 - Grommet Remove Screw (B1) from Clamp Bolt (B2) and remove Clamp Bolt (B2) from Clamp (B). Remove protective film from Pads (I) and apply them to the bottom side of Grommet Plate (H).
Page 7
Grommet - Cont’d Align the Pin on top of Grommet Plate (H) with the Small Hole on the bottom of Lower Pole (C) and position the parts over the grommet hole. Attach to the desktop using Support Plate (E) and Clamp Bolt (B2). Small Hole My Desk Does Not Have a Grommet...
Page 8
STEP 2 Slide Pole Cable Clip (G) and one of the VESA Brackets (A) onto the Lower Pole (C). Adjust the height location of the VESA Bracket and tighten using the 6mm Allen Wrench (T-B).
Page 9
STEP 3 Place Pole Cap (F) on top of Upper Pole (D), then screw the Upper Pole onto the Lower Pole (C). Slide the remaining Pole Cable Clip (g) and VESA Bracket (A) onto the Upper Pole. Ad- just the height location of the VESA Bracket and tighten using the 6mm Allen Wrench (T-B).
Page 10
STEP 4 Loosen the Thumbscrew (A2) on the back of both VESA Brackets (A1), then separate and remove VESA Plates (A3) by pulling out and sliding upwards. Install the VESA Plates (A3) onto the back of your monitors using M4x12mm Screws (M-A) or M5x12mm Screws (M-B) and M5 Washers (M-C), orienting the arrow on the VESA Plates pointing up.
Page 11
STEP 5 Adjusting the Tilt Joint Adjustment Screw Loosen Tilt Joint: Set Angle Use 6mm Allen Wrench (T-B) to Firmly grip the VESA Bracket and loosen the Tilt Joint Adjustment adjust to your desired viewing Screw, located on the side of angle, and hold in place.
Page 12
STEP 6 With the assistance of a second person, line up the VESA Plates (A3) on your monitors with the VESA Bracket (A1) and the Plate Hooks into the pockets of the VESA Brackets. Monitor & VESA Brackets may need to be angled backwards slightly when sliding on. 2 Person Mounting is Recommended *Monitor &...
Page 13
Fine Tune Tilt Angle If the monitor is angled further than intended... Heavy Weighted/ Ultrawide Monitors [ 22lbs - 44lbs ] Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the...
Page 14
STEP 7 Route cables through Pole Cable Clip (G) and store Allen Wrenches provided slots. STEP 8 Make adjustments as desired on swivel and orientation.
Page 15
*If you are using the stand with the clamp, do NOT extend the arm past the back of the clamp to prevent possible damage to your monitor and stand.
