Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V200B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v200b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V200B and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V200B

  • Page 1 Dual Monitor Desk Mount Instruction Manual SKU: STAND-V200B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v200b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6lbs Failure to do so may result in serious injury. (8 kg) PER SCREEN Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach the pole cap (G) to the top of the pole (B). STEP 2 Attach the pole (B) to the clamp (C) using M6x12 bolts (H) and tighten using the 4mm Allen wrench (K).
  • Page 4 STEP 3 Slide the pole cable clip (E) and arm (A) onto the pole (B) and tighten using the 6mm Allen wrench (L). Attach the arm cable clips (F) to the arm (A). STEP 4 OPTION A: Flat Back Monitor Attach the VESA plates (D) to the monitors using bolts (M-A or M-C) and washers (M-E).
  • Page 5 STEP 4 (Continued) OPTION B: Curved Back Monitor Attach the VESA plates (D) to the monitors using bolts (M-B or M-D), washers (M-E) and spacers (M-F). Tighten with a Phillips screwdriver. STEP 5 Slide the VESA plates (D) onto the arm (A) and secure using the knobs (J) with M3x8 bolts (I).
  • Page 6 STEP 6 Tighten or loosen the tilt joint using the 6mm Allen wrench (L). STEP 7 Route cables through the cable management clips (E,F).
  • Page 7 STEP 8 Turn the knobs (J) by hand or using the 6mm Allen wrench (L) to adjust the monitor height for leveling. Store tools in the cable clip.
  • Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
