- Page 1 INSTALLATION GUIDE AND USERS MANUAL PROFESSIONAL ISLAND RANGE HOOD TWISTER MAX ISLAND Model Name: 36”, 42” Available Sizes: NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference. Rev.20230406...
-
Page 2: Table Of Contents
Grease Tunnel & Filters..............21 Wiring Diagram................. 22 Range Hood Operations..............22 Troubleshooting................23 Do’s and Don’ts for Duct Venting............ 24 Use and Care Information..............24 Maintenance..................25 Bulb Replacement................26 Warranty..................... 28 Disclaimer..................29 Contact Us..................29 | TWISTER MAX ISLAND... -
Page 3: Important Safety Notice
• Use high settings on cooking range only when necessary. • Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. TWISTER MAX ISLAND | 3... - Page 4 The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. | TWISTER MAX ISLAND...
-
Page 5: Electrical Requirements
(at the range hood and at the junction box). Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 TWISTER MAX ISLAND | 5... -
Page 6: Venting Requiremens
If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood mounting height above range. Minimum Duct Size: • Round - 8” minimum • Round - 10” recommended/optional * Due to different ceiling height configurations, recommended height may not be applicable. | TWISTER MAX ISLAND... -
Page 7: Calculating Duct System Length
4 x 35W or 6 x 35w GU10, 120V Dimmable (LED Optional) Ducting Size Top 8 Inches Round or 10” (Optional) Warranty 5 YEARS ( parts warranty ) Subject to change without notice, please contact your local reseller for details. TWISTER MAX ISLAND | 7... -
Page 8: Required Tools
Power Knife Knife Knife Drill Tape Phillips Measure Screwdriver Level Aluminum Tape PARTS SUPPLIED NOTE: Where necessary, additional screws will be needed for installation and added support, but is not included. Please review contents before installation. | TWISTER MAX ISLAND... - Page 9 PARTS SUPPLIED (Continued) Frame Support (with extensions) Lower Chimney Upper Chimney Ø - 10” Transition (Requested option) Ø - 8” Transition Corner Baffle Filters (x6) Brackets (x4) Grease Tunnel (x2) Range Hood TWISTER MAX ISLAND | 9...
-
Page 10: Dimensions
Ø 10” Ø 8” 34” 35 ¾” 14 ¾” FRONT SIDE VIEW VIEW 16 ¾” 4” Hood shown: TWISTER MAX ISLAND 36” Please refer to next page for available models and their respective dimensions BOTTOM VIEW | TWISTER MAX ISLAND... - Page 11 15 ¾” to 23” 11 ¾” Ø - 8” 4” Vent Size 4” 16 ¾” A A vailable Sizes: Available Sizes: vailable Sizes: 35 ¾” 35 ¾”, 41 ¾” ¾”, 41 , 41 ¾” ¾” 34” TWISTER MAX ISLAND | 11...
-
Page 12: Preparation
12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed. 7. Disconnect power cord, remove the stainless steel baffle filter and grease tunnel. 8. Set aside the stainless steel baffle filters and grease tunnel until the range hood is properly installed. | TWISTER MAX ISLAND... -
Page 13: Pre-Installation
(3) Thread the electrical outlet and duct through (4) Screw the frame onto the drywall where the the main frame of the range hood support. wood braces are which will provide support. TWISTER MAX ISLAND | 13... - Page 14 (3) Thread the electrical outlet and duct through (4) Screw the frame onto the drywall where the the main frame of the range hood support. wood braces are which will provide support. | TWISTER MAX ISLAND...
-
Page 15: Installation
Before connecting wires, switch power off at service panel and lock service panel to preduct power from being switched on accidentally. TWISTER MAX ISLAND | 15... - Page 16 (2) Screw on 8”-Ø transition (10”-Ø optional) to of the top of the range hood. the opening of the fan motor exit. (3) Attach a flex duct (not included) to the (4) Use aluminum foil tape to secure a proper transition. seal. | TWISTER MAX ISLAND...
- Page 17 (7) Fasten arm extensions to the brackets with a (8) Slip on the chimney sleeve over the arm screw on each side of each bracket with locking extensions while ensuring the power cord also nut. slips through the sleeves. TWISTER MAX ISLAND | 17...
- Page 18 NOTE: Use a stable platform to rest the range hood and/or receive assistance to hold on range hood. Connect the flex duct from the range hood to the ducting in the ceiling. Use aluminum foil tape to secure a proper seal. | TWISTER MAX ISLAND...
- Page 19 (12) Lift the inner sleeve of the chimney, and plugging in to outlet. Check the fan motor and raise to the main frame. Fasten screws to each lights are functioning. of the hole openings and ensure a secure fit. TWISTER MAX ISLAND | 19...
-
Page 20: Venting Methods
96” • Colder climates require wrapping *Max: 108” insulation around the ducts and optional blowers. • The system must have a Backdraft Damper. * Due to different ceiling height configurations, recommended height may not be applicable. | TWISTER MAX ISLAND... -
Page 21: Grease Tunnel & Filters
Place Grease Tunnel into the hood opening and insert into slot holding, as shown above. (3) Lower filter while sliding back until it rests onto Grease Tunnel. TWISTER MAX ISLAND | 21... -
Page 22: Wiring Diagram
The switch has 5 positions: OFF, SPEED 1,2,3,4. LIGHT SWITCH: Rotate the switches clockwise to switch the lights ON. The light switch allows you to control the intensity of the light via rotary Typical rotary switch dimmer. | TWISTER MAX ISLAND... -
Page 23: Troubleshooting
NO reducers or plenums in the duct work. • Refer to DO’S and DON’TS for DUCT VENTING page for illustrative examples. NOTE: For all other inquiries, please contact Victory Range Hoods. TWISTER MAX ISLAND | 23... -
Page 24: Do's And Don'ts For Duct Venting
DO NOT operate blowers when filters are removed. Never disassemble parts to clean without proper instructions. Disassembly is recommended to be performed by qualified personnel only. Read and understand all instructions and warnings in this manual before proceeding. | TWISTER MAX ISLAND... -
Page 25: Maintenance
Dry the filters and re-install before using the hood. Replacing Filters: • Should filters wear out due to age and prolonged use, please contact Victory Range Hoods to order replacement filters. NOTE: For all other inquiries, please contact Victory Range Hoods. -
Page 26: Bulb Replacement
Twist the connector cap off, and dislodge from electrical tether. LED Bulb is model: GU10. Contact Victory Range Hood and place an order, or you may purchase at your nearest hardware store. | TWISTER MAX ISLAND... - Page 27 To re-assemble, simply reverse the steps press the bulb housing carefully and firmly into the recess, until you hear a positive snap. *Observe all safety precautions before you proceed to turn ON breaker and range hood to test for operation. TWISTER MAX ISLAND | 27...
-
Page 28: Warranty
Victory Range Hoods. The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. | TWISTER MAX ISLAND... -
Page 29: Disclaimer
Toll Free: 1-800-394-4020 info@victoryrangehoods.com The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. TWISTER MAX ISLAND | 29... - Page 30 NOTES | TWISTER MAX ISLAND...
- Page 31 NOTES TWISTER MAX ISLAND | 31...
- Page 32 583 Nicola Avenue | Port Coquitlam | BC | Canada | V3B 0M3 www.victoryrangehoods.com...
