- Page 1 INSTALLATION GUIDE AND USERS MANUAL Ceiling-Mount Range Hood SUNSET Model Name: NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference. Rev. 3062u.3a...
-
Page 2: Important Safety Notice
Always turn range hood ON when cooking at high heat or when cooking foods that produce flames. • Use high settings on cooking range only when necessary. • Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. | SUNSET... - Page 3 The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. SUNSET...
-
Page 4: Required Tools
REQUIRED TOOLS | SUNSET... -
Page 5: Venting Requirements
Reducing the duct size will restrict airflow and decrease efficiency. • If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible. Minimum Duct Size: • Round - 6” minimum SUNSET... -
Page 6: Calculating Vent System Length
Subtract 30ft from the allowable 50ft. The remaining distance of 20ft is the used longest that the straight ducting (in ad- Side wall cap with damper 7 ft dition to the vent pieces) can be. Roof cap 7 ft | SUNSET... -
Page 7: Electrical Requirements
(at the range hood and at the junction box). Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 SUNSET... - Page 8 Try to avoid as many transitions, elbows, and long run as possible. This may reduce the performance of the hood. • Using 45 degee elbows is better than using 90 degree elbows. • IMPORTANT: Peel white plastic protective coat off the hood, if any. • Use aluminum tape to seal joints between pipe sections. | SUNSET...
-
Page 9: Installation & Diagrams
INSTALLATION & DIAGRAMS Installation: The range hood should be placed at a maximum distance of about 8’ from the floor for best performance. The ceiling should be able to bear 27 Kg in weight. SUNSET... -
Page 10: Venting Methods
Use caulking to seal exterior wall or roof opening around the cap. • If the duct is running though a cold section of the house (attic space), insultion of the duct will be required to prevent condensation (refer to sketch below). | SUNSET... - Page 11 DIMENSIONS & CUT OUT SUNSET...
- Page 12 Please NOTE: The orientation of the joists and the orientation of the stove must match. If the orientation does not match, the range hood may need to be dropped down into a box in order to rotate it. | SUNSET...
-
Page 13: Wiring Diagram
WIRING DIAGRAM SUNSET... -
Page 14: Range Hood Operations
• This hood will come with a Wall Switch to operate the lights and motor. • The lights have an On/Off switch and are dimmable. The motor has a 4-speed switch. HOOD WALL SWITCH FRONT* BACK* ROTARY FAN SWITCH LIGHT DIMMER SWTICH 4 SPEEDS *The wall switch may slightly vary | SUNSET... -
Page 15: Troubleshooting
Reduce the number of elbows and length of duct work. Check if all joints are properly con- nected, sealed, and taped. • Make sure the power is on high speed for heavy cooking. NOTE: For all other inquiries, please contact Victory Range Hoods. SUNSET | 15... -
Page 16: Specifications
6 inch Round (Side or Top*) *Must select before purchase 1. In House Test Static Pressure “0”. 2. One sone is roughly equivalent to the sound of a refrigerator (1kHz) at 40 decibels. 3. Subject to change without notice, please contact your local reseller for details. | SUNSET... -
Page 17: Maintenance
® very dirty. Dry the filters and re-install before using the hood. Replacing Filters: • Should filters wear out due to age and prolonged use, please contact Victory Range Hoods for replacement filters. Replacing the light bulb: • This range hood uses LED bulbs (please refer to the actual specification of the hood purchased): USA/Canada: LED 5.5W Type GU10 120V... -
Page 18: Warranty
Subject to the conditions and limitations set forth below, Victory Range Hoods will, at its option, either repair or replace any part of its products that prove defective by reason of improper workmanship or materials. Repaired parts or replace- ment products will be provided by Victory Range Hoods on an exchange basis, and will be either new or refurbished to be functionally equivalent to new. - Page 19 Toll Free: 1-800-394-4020 info@kitchenhoods.ca The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. SUNSET...
- Page 20 583 Nicola Avenue | Port Coquitlam | BC | Canada | V3B 0M3 www.kitchenhoods.ca...
