Installation Guide
and Users Manual
VICTORY
Built-in Range Hood
IMPORTANT:
Model number: E70
Read and save these instructions.
available size: 30", 36"
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Built-In Range Hood Users Manual
Rev. 1052u.3a
Advertisement
Table of Contents
Related Manuals for Victory E70
Summary of Contents for Victory E70
- Page 1 Installation Guide and Users Manual VICTORY Built-in Range Hood IMPORTANT: Model number: E70 Read and save these instructions. available size: 30”, 36” NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Built-In Range Hood Users Manual...
-
Page 2: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. -
Page 3: Venting Requirements
Important Safety Notice Venting Requirements Height & Clearance Read all Instructions before Installing and operating this appliance • Vent system must terminate to the out- side (roof or side wall). • Do not terminate the vent system in an • Clean ventilating fan frequently. Cabinet attic or other enclosed area. -
Page 4: Venting Methods
Venting Methods IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- • This built-in range hood is factory set for venting through the roof or wall. ly) must be used to maintain maximum airflow efficiency. •... -
Page 5: Electrical Requirements
Electrical Requirements Installation IMPORTANT: Observe all governing codes and ordinances. (THIS HOOD REQUIRES 120V POWER TO OPERATE PROPERLY) It is the customer’s responsibility: To contact a qualified electrical installer. To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 —... -
Page 6: Range Hood Operations
Range Hood Operations Troubleshooting Turn On: 1. If the range hood does not operate after installa- • Check if the range hood has been plugged in, make tion: sure that all power has been turned back on and all • Press the speed control (Low Speed, Medium Speed, High Speed) switch to select the desired level of electrical wiring are properly connected. -
Page 7: Maintenance
Use and Care Information Maintenance WARNING — TO REDUCE THE RISK OF FIRE, ELEC- lowed to accumulate on fan or filter. SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! TRIC SHOCK, OR INJURY TO PERSONS, OBSERVE Use proper pan size. -
Page 8: Warranty
Maintenance Warranty (Continued) Replacing the Light Bulb Using the Inner Ring Opener: • Make sure the range hood is unplugged or turn OFF breaker. TO OBTAIN SERVICE UNDER WARRANTY: • Make sure the lights are cool to touch, carefully align the arrow on the inner ring with the arrow on the outer ring where You must present proof of original purchase date. -
Page 9: Your Notes
Disclaimer Your Notes Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 10 Burnaby, BC, Canada www.KitchenHoods.ca tel. 604 430 5252...
