PCE-3029/PCE-4129 LGA1151 Intel

Core™ i7/i5/i3/Celeron

System Host Board with DDR4/Dual GbE LAN

Startup Manual

Packing List

Before you begin installing your card, please make sure that

the following items have been shipped:

1. 1 x PCE-3029 or 4129 PICMG 1.3 System Host Board

2. 1 x CD with utility

3. 1 x PCE-3029/PCE-4129 Startup Manual

4. 1 x Serial ATA HDD data cable

5. 1 x Serial ATA HDD power cable

6. 1 x 2-port COM cable kit

7. 1 x 4-port USB 2.0 cable kit

8. 1 x 2-port USB 3.0 cable kit

9. 1 x Power converter (Connecting from peripheral power

connector on power supply to PWR1 on board)

10. 1 x Keyboard and mouse Y cable

11. 1 x Jumper package

12. 1 x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1:

For detailed contents of PCE-3029/PCE-4129,

please refer to information on the enclosed CD-

ROM (in PDF format).

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

This manual is for the PCE-3029/PCE-4129 Series

Rev. B3.

Part No. 2001302911

Printed in China

/Pentium

Specifications

General

• CPU: LGA1151-socket Core™ i7/i5/i3, Pentium® and

Note: Only PCE-4129 supports Intel® Xeon® processors.

• L2 cache: Please refer to CPU specification for detailed

• BIOS: AMI SPI BIOS (128 Mb SPI)

• System chipset: Intel® C236 (PCE-4129); Intel® H110

• System memory:

• SATA hard disk drive interface: PCE-3029 sup-

• Serial ports: Two RS-232 serial ports

• Keyboard/mouse connector: Supports one external

• Watchdog timer: Programmable 1~255 sec

• USB: USB 3.0 x 3, USB 2.0 x 7

• GPIO: One programmable 8-bit GPIO pin-header

Display

• Chipset: Intel

Ethernet Interface

• Chipset supports:

• Connection: 2 x on-board RJ-45 connectors with LED

Mechanical and Environmental

• Dimensions: (L x W): 167.64 x 126.39 mm

• Power supply voltage: +3.3 V, +5 V, +12 V, 5 V

• Power requirements:

PCE-3029:

Intel® Core™ i7-6700 (3.4GHz), DDR4 2133 8GB * 2

Voltage

Current (A) 4.6

2nd Edition

October 2022

Xeon®,

PICMG1.3 Half-size

Xeon® E3-1200v5 series processors

information.

(PCE-3029)

- PCE-4129: Up to 32 GB in two 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 1866/2133 SDRAM

with or without ECC function.

- PCE-3029: Up to 32 GB in two 260-pin SODIMM sock-

ets. Supports dual-channel DDR4 1866/2133 SDRAM

without ECC function.

ports three SATA 3.0 ports without RAID function, and

PCE-4129 supports four SATA 3.0 ports with SW RAID

0,1,5,10.

6-pin header

HD Graphics embedded in the processor

LAN 1: Intel

I219V (PCE-3029) and I219LM (PCE-4129).

- LAN 2: Intel

I210AT (PCE-3029) and I210AT (PCE-4129).

indicators

12V

0.01

PCE-3029/PCE-4129 Startup Manual 1

3.3V

-12V -5V

0.32

0.08
