- Page 1 AN1404 QUICK INSTALLATION GUIDE AN1404 4G Door Station Layout This 4G Door Station is suitable for both flush and surface mounting. Speaker Call Button Microphone Connector Antenna (Rear View) (Front View) (Surface Mounting Enclosure) (Side View) AN1404 4G Door Station...
- Page 2 4. Put the main station unit into the enclosure and fasten it with screws on top and bottom. 5. Connecting the flat cable (BLUE side face up) back to the back panel 6. Fasten the front panel with security screws AN1404 4G Door Station...
- Page 3 Register your SIM card with the network, and check it works in a mobile phone You MUST remove the PIN code from the SIM before inserting it in the AN1404. Ensure the power is OFF before inserting the SIM card. Carefully slide the SIM holder in the OPEN direction, insert the SIM, and slide in the CLOSED direction to lock it in place.
- Page 4 2. LED ‘Network “Indicator Status Green (ready) 1 sec ON/ 1 sec OFF Green (searching) Solid Green (busy) Solid 3. LED “ Power “ Indicator Status Red (power on) Solid Red (power off) AN1404 4G Door Station Revision E11 March 2023...
