- Page 1 AN1912 4G Video Intercom Aristel 4G VIDEO INTERCOM (ACCESS CONTROL SYSTEM) For your protection, read these instructions completely And keep them for future reference. Aristel V1.43 1/21...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS ........................... 3 INTRODUCTION ................................4 PARTS LIST .................................. 4 INSTALLATION ................................5 AN1912 4G VIDEO INTERCOM UNIT ..........................7 OPERATING THE AN1912 ............................7 USE DOOR INTERCOM APP ............................7 REGISTER PHONE NUMBER ACCOUNT ........................8 ADD DEVICE (ADMINISTRATOR) ..........................9 ADD ROOM (ADMINISTRATOR) ..........................11... -
Page 3: Important Safety Instructions
AN1912 4G Video Intercom Thank you for purchasing the AN1912 4G video intercom. Please read this manual carefully before using. Be sure to keep this manual for future reference in case of any problem or question should arise. Important Safety Instructions 1. -
Page 4: Introduction
AN1912 4G Video Intercom Introduction The AN1912 4G video intercom system is designed for apartment blocks, multi-family residential and gated communities. It supports up to 1000 householders. When a visitor enters the apartment’s number on the intercom, it will then call the relevant smartphone APP, once the call is answered, you can speak to and view the visitor and you can open the door or gate from your smartphone. -
Page 5: Installation
AN1912 4G Video Intercom Installation NOTE: This 4G video intercom is suitable for surface mounting. NOTE: install suggestion Fix the video intercom on the wall by screws. The view angle of this video intercom should be around 80°. The height of the lens position is... - Page 6 AN1912 4G Video Intercom NOTE: If you want to reset the Fail safe internet setting of the device, press the RESET button about 5 to 10 seconds until you hear the remind tone. NOTE: The setting of 12V-24V Network and APN will be...
-
Page 7: An1912 4G Video Intercom Unit
AN1912 4G Video Intercom AN1912 4G Video Intercom Unit Lens Infrared light RFID Microphone Server connection 7-Segment LED 1: disconnected Display connected NOTE: After power on, press any number key to query the current status Keypad of the device Speaker... -
Page 8: Register Phone Number Account
AN1912 4G Video Intercom Register phone number account Note: Administrator and all residents 2.Select server (Default 1.press “Login by Europe) please follow the steps to install the App account and password” 3.Register the account and register their account. 4.Select country code 7.Enter password... -
Page 9: Add Device (Administrator)
AN1912 4G Video Intercom Add Device (only works for Administrator account) 1.Add network connected device 1.Press “+” add 2.Press “add network 3. Make sure the device 4.Select device device connected device” is connected to the 5.press “next” Internet and press "next"... - Page 10 AN1912 4G Video Intercom 2.Add 4G Device 1. Press “+” add 2.Press “add 4G 3. Scan device QR Code device Device” 4. Enter “Password” (Red frame) 5.Press “add device to account” １ ３ ４ ２ ５ Wait for the device to set 6.
-
Page 11: Add Room (Administrator)
AN1912 4G Video Intercom Add Room (only works for Administrator account) 1.Press “Resident” 2.Press “+” icon 3.Enter the room icon number (5 digits) and press “ok” ２ ３ １ Add Resident (only works for Administrator account) 1.Select “Room” list 2.Press “+” icon 3.Enter the phone... -
Page 12: Add Rfid Card (Administrator)
AN1912 4G Video Intercom Add RFID Card (only works for Administrator account) 1.Press “Resident” 2.press “Room” icon 3.Press “+” icon 4.Select “Card” icon 5.press “ok” １ Scan the card 2 times 6.Card scan the device 2 7.when add card ok,... -
Page 13: Setting Pin Code(Administrator)
AN1912 4G Video Intercom Setting PIN code (only works for Administrator account) 1.Press “PIN code” 2.Press “+” icon 3.Enter the password. Set PIN code finish icon (5 digits) 4.Press “OK” ２ ３ １ ４ Setting Admin password (only works for Administrator account) 1.Press “Admin... -
Page 14: Setting Record Video (Administrator)
AN1912 4G Video Intercom Setting record video (only works for Administrator account) 1.Confirm the TF card 2.Press the “Detail” 4.Press the “OK”, and 3.Press the “Formattable” is inserted icon setting finish ３ ２ １ ４ NOTE: 15 minutes for each recording, wait 15 minutes for the first setting before you can watch the... -
Page 15: Setting Alarm Zone (Administrator)
AN1912 4G Video Intercom Setting alarm zone (only works for Administrator account) 1.Setting alarm zone 1.press “Click to configure” 2.AI face detection: Click to change location(nickname) ２ 3.Activate 24hrs alarm: Alarm will also sound when disarmed ３ 4.Sensor alarm plan: ４... -
Page 16: Delete Device (Administrator)
AN1912 4G Video Intercom Delete device (only works for Administrator account) Note: The device will be deleted from the App of smartphones of administrator and all residents. And the device will be restored to all default settings. 1.press the “Delete”... - Page 17 AN1912 4G Video Intercom How to update the device (only works for Administrator account) 1.Choose door video intercom 2.Press “Detail” If there is a device firmware update, an update window will pop up 3. Confirm update, press “OK” １ 4. Confirm updated version, press Wait for the update to complete 5.
-
Page 18: Setting Pin Code (Resident)
AN1912 4G Video Intercom Resident APP setting Setting PIN code (Resident) 1.Press “PIN code” 2.Press “+” icon 3.Enter the password Set PIN code finish icon number (5 digits) 4.Press “OK” ２ ３ １ ４ Delete device (Resident) 1.press the “Delete” icon 2.Remove shared system, and... -
Page 19: Watch Live Video (Monitoring Mode)
AN1912 4G Video Intercom Watch live video (monitoring mode) NOTE: The microphone and the speaker are disabled, watching and unlocking time is 30 seconds. Icons description 1.Press the device list 2. Press the play icon 1. Close video 2. Shrink video 3. -
Page 20: Specifications
AN1912 4G Video Intercom AN1912 Specifications: Image Sensor 1/2.7” 2MP CMOS Image Compression H.265 Image Frame Rate 25fps maximum Resolution 1080P(1920 x 1080), VGA(720 x 576) Video Lens 2.8mm Angle of View H:90° V:80° Day Vision Color Image, auto switch IR-CUT... -
Page 21: Q&A
AN1912 4G Video Intercom Q&A: Q1: After inserting a 4G SIM card, how to check if the device is registered to a mobile network? A1: Press any key on the device, the current status of the device will be showed on the display - LED2 is OFF when 4G SIM is registered. - Page 22 AN1912 4G Video Intercom Q4: How can I adjust the volume of Microphone and Speaker? 1. The device is connected to the 2. Tap the magnifying glass symbol 3. Get IP location LAN, the mobile phone and the on the mobile APP login screen...
