- Page 1 AN1808-08 4G QUICK INSTALLATION GUIDE Installation This 4G audio intercom is suitable for both flush mounting and surface mounting. 4G AUDIO INTERCOM 4G AUDIO INTERCOM (FLUSH MOUNTING) (SURFACE MOUNTING) AN1808-08 4G...
- Page 2 AN1808-08 4G QUICK INSTALL GUIDE 1. SIM card installation (Fig 1) 1.1 Disconnect the 12V adaptor from the AN1808-01 1.2 Remove the rear plastic cover 1.3 Remove the SIM card cover from the bottom of the unit 1.4 Slide the SIM card holder towards the front of the unit 1.5 Lift up the holder...
- Page 3 AN1808-08 4G QUICK INSTALL GUIDE 2. Connecting with the door lock system (Fig 2) 2.1 According your door lock type to wire with door latch of connector. 3. Connecting the Antenna (Fig 3) 3.1 Plug on the antenna cord to the connector on the rear of the unit 3.2 Place antenna away from electrical/electronic systems (computers,...
- Page 4 AN1808-08 4G QUICK INSTALL GUIDE 4. Power on and Fix it well 4.1 Connect the power adaptor into the connector marked AC 4.2 The blue indicator of call button should be on and you will hear Du Du tone. 4.3 Fix the unit on the position before ready.
- Page 5 AN1808-08 4G QUICK INSTALL GUIDE Using the AN1808-01 1. Setting your call out numbers i) Send the text SMS to the number of device. ii) The format of text SMS is *12*1234#11[call out number 1]#12[call out number 2]#13[call out number 3]#...
