ARISTEL NETWORKS
MANUAL
3G AUDIO DOOR INTERCOM
Suitable for
UP TO 200 APARTMENTS
(ACCESS CONTROL SYSTEM)
For your protection, read these instructions completely
And keep them for future reference.
AN1204A ( E/J ) O-K12H-2
1
Version ARB3-1, July 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN1204AO-K12H-2 3G and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel AN1204AO-K12H-2 3G

Summary of Contents for Aristel AN1204AO-K12H-2 3G

  • Page 1 ARISTEL NETWORKS MANUAL 3G AUDIO DOOR INTERCOM Suitable for UP TO 200 APARTMENTS (ACCESS CONTROL SYSTEM) For your protection, read these instructions completely And keep them for future reference. AN1204A ( E/J ) O-K12H-2 Version ARB3-1, July 2016...
  • Page 2 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ..............3 AN1204AO-K12H-2 3G INTERCOM INTRODUCTION ........... 4 AN1204AO-K12H-2 3G INTERCOM WITH ACCESSORIES ........4 INSTALLATION....................... 5 AN1204AO-K12H-2 3G Intercom Unit ............... 5 Wiring Diagram ......................5 LED Indicator ....................... 6 AN1204AO-K12H-2 3G INTERCOM OPERATION............ 7 Enter Listener Monitoring Mode ..................

  • Page 3: Important Safty Instructions

    Thank you for purchasing AN1204AO-K12H-2 3G Intercom. Please read this manual carefully before using. Be sure to keep this manual for future reference in case of any problem or question should arise. IMPORTANT SAFTY INSTRUCTIONS When using this AN1204AO-K12H-2 3G Intercom, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury.
  • Page 4 By pressing the call button, and then entering the 2 or 3 digit apartment or villa number, the intercom will call up to 3 preprogrammed telephone numbers belonging to the resident(s) of that villa. AN1204AO-K12H-2 3G INTERCOM WITH ACCESSORIES Item Description Qty.

  • Page 5: Installation

    INSTALLATION AN1204AO-K12H-2 3G Intercom Unit Keypad Speaker Call Microphon Wiring Diagram AN1204A ( E/J ) O-K12H-2 Version ARB3-1, July 2016...

  • Page 6: Led Indicators

    LED INDICATORS 1. LED “Intercom Status “ Indicator Keypad LED Status Yellow (standby) Flashes once per 5 seconds Yellow (using) Solid 2. LED ‘Network “Indicator Status Green (ready) Flashes once per 3 seconds Green (searching) Flashes once per second Green (busy) Solid 3.
  • Page 7 AN1204AO-K12H-2 3G INTERCOM OPERATION When the visitor pushes the call button and enters the house number to activate the door intercom, ring tone will be heard from the 3G intercom. At the same time, connection is established with the phone number that is stored in the intercom.

  • Page 8: Enter System Menu

    Enter valid 1~14 digit PIN code Enter system menu There are three different modes under the system menu. Listener monitoring mode Access control mode Programming mode To gain access to the system menu by call, follow these steps: Call the telephone number of the 3G intercom Wait for the intercom to answer and signal by one beep to enter system menu Enter the password of the mode you would like to enter Password correct is one beep, password error is 3 beeps.
  • Page 9 Enter Listen & Monitoring Mode Call the telephone number of the 3G intercom This device will then verify your phone number with your predefined numbers. You will hear a “Do” tone to enter listener monitoring mode by pressing【*13*1212＃】 where 1212 is the password. You are now in the”...
  • Page 10 * Under this mode speaker is OFF.( 35＃: turn on speaker ) * You can still control the relay output when you are under listen & monitoring mode, but the speaker must be ON status. Enter Access Control Mode Call the telephone number of the 3G intercom . This device will then verify your phone number with your predefined numbers.
  • Page 11 Programming Programming can be carried out either by dialing into the 3G intercom or by sending a text message (Certain programming feature can only be set up by text message, please refer to user commands P.15) Programming by text message Programming by text message is the simplest way to customize the settings of the 3G intercom and add or delete telephone numbers.
  • Page 12 Example 2: Program access control by phone For Caller ID recognition to control access you need to program the mobile numbers and country code into the memory before using. Ireland Country code: 353 (UK: 44 / USA: 1) 086 5683624 (mobile number 1) 086 5682554 (mobile number 2) 086 2235644 (mobile number 3) Command to use: *12*1234#71...

  • Page 13: Check Relay /Detect Status

    Call the telephone number of the 3G intercom Enter Programming Mode by Pressing….. *12*1234# (1234 is default password) A successful password code will produce a single long beep. A failed attempt will produce 3 short bleeps. You may now program a telephone number into memory. Use the following commands to program the unit * Insert international country code (1~3 digits): 71 [ country code] # * Add a number (up to 1150 numbers):72 [relay][telephone number] #...

  • Page 14: Administrator Number

    the gates are open or closed. Administrator Number Once the administrator number is stored, the unit will only accept programming from this number and only via SMS programming. Example: Program a mobile number as an administrator number via SMS Mobile number: 0865682554 Command to use *12*1234#74 [Admin number]# *12*1234#740865682554# SMS format...
  • Page 15 address, e-mail sender name# Type= 1 general format Type= 2 SSL format (Gmail must be used) Command code Example : *42*1234# recipient e-mail address, recipient name, carbon copy e-mail address, carbon copy name# Recipient & Carbon copy settings Commande code example: Function SMS command codes E-mail subject setting...
  • Page 16 time correction Remark: why you need to setup the number for system time clock date and time correction? This device has a time clock and supports automatically updating their date and time via NITZ information from network. In case some of the networks are not available for NITZ information, we strongly suggest to setup this clock date and time correction.
  • Page 17 Example: Mobile number for receiving a log 0907967223 SIM phone number used in intercom 0948778458 *12*1234#841#850907967223#860948778458# Send *44*1234# to check log To gain access to the different modes and control relay (by dial in) Function command Description Default Enter Programming Mode *12* [ password ] # Programming by calling 1234...
  • Page 18 SMS content (default 1234) All call button phone number *27* [ password ]# 00-TEL1,TEL2,TEL3, report 01-TEL1,TEL2,TEL3, ------------, 99-TEL1,TEL2,TEL3 Signal house call button phone Successful reply: *28*[password]#[X~X], TEL1, number report House number TEL2, TEL3, PW1, PW2, PW1-PW2-PW3-PW4-PW5-PW6 PW3, PW4, PW5, PW6# (if no data, please don’t keep TEL1 space)
  • Page 19 User commands table You can program many different user command codes in one text message with SMS command format. *12*1234 # [command Code1] # [command Code 2] # [command Code3] #..Feature Command Description Default Change programming 01 [ password ] # password:4 digit codes 1234 Password...
  • Page 20 74*# delete administrator phone number Del admin phone number None N= 0 or 1 0= disable / 1= enable SMS replay Relay control SMS reply 894+N# Relay 1 trigger, relay 2 trigger Relay 1 hold, relay 2 hold Relay 1 release, relay 2 release Reset 999# reset default...
  • Page 21 Disable, enable Call button 896+X# X=0 (disable) LED flashing X=1 (enable) disable, enable keypad 897+X# X=0 (LED ON) LED light X=1 (LED OFF) Dial tone volume 898+X# X=1~4 ( levels) Egress (PB pin on PCB) 900+ relay# X=0 (relay 1) X=1 ( realy2) Egress( 901+ relay#...

  • Page 22: Specification

    SPECIFICATION: Model AN1204AO-K12H-2 / AN1204EO-K12H-2 Operating Voltage 12~24 Volt AC/DC Operating Current Maximum 250 mA, Typically 55mA 3G / WCDMA Module Simcom 3G / WCDMA Frequency GSM 850/900/1800/1900 Mhz, WCDMA 850/2100 or 900/2100 Mhz Physical size Face plate: 260(W) x165(H) mm, Stainless cabinet:260 (W) x 165(H) x 120 (D) mm Physical material Stainless Steel Humidity...

  • Page 23: Quick Programming Via Sms And Operation

    Quick programming via SMS and operation Programming: Program house number with call button phone number. (Max 200 house numbers) Note: To program call button numbers DO NOT enter country code, just the complete number as you would dial it. Command to use: *28*[password]#[X~X], TEL1, TEL2, TEL3, PW1, PW2, PW3, PW4, PW5, PW6# X~X= house number, 1 to 6 digits.

  • Page 24: Operation

    99-NN-NN-NN-NN-NN 0428313884 Program access control by phone (1150 numbers) Command to use: *12*1234#71[country code]#72[relay][ phone number] #72[relay][ phone number] #72[[relay] phone number] #..Example: Ireland Country code: 353 (UK: 44 / USA: 1) 086 5683624 (mobile number 1) 086 5682554 (mobile number 2) 086 2235644 (mobile number 3) SMS format: *12*1234#71353#7210865683624#7220865682554#7210862235644# Program PIN code access control by keypad (384 PIN user codes)

  • Page 25: Troubleshooting (Q &A)

    Send SMS or call to control relay *33*5678# (trigger relay 1) *36*5678# (trigger relay 2) *34*5678# (hold relay 1) *37*5678# (hold relay 2) *35*5678# (release relay 1) *38*5678# (release relay 2) *20# (check reception level) *21# (check stored number) *22# (check relay / detect status) *24*1234# (check stored PIN code) *44*1234# (check log) Enter valid PIN code to control relay...
  • Page 26 Q. The unit calls the first number, but there is not enough time to answer before it diverts to the next number. A. Increase the no answer time as per programming instructions. Q. The unit calls the first number but voicemail comes on before it can ring the second number. A.
  • Page 27 Station, Door Station will call back to the sender’s number to enter monitoring mode. (ii) Admin number is set. Door Station can accept SMS code from admin number only. The SMS sent from another number will be ignore. www.aristel.com.au ph: (03 )85422300 fax:(03)95443299...
