SINGLE POST PARKING LIFT
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must notate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
Address:
SC Division: 1931 Joe Rogers Jr Blvd, Manning, SC 29102, USA
TX Division: 4310 Adler Dr., Suite #200, Dallas, TX 75211, USA
MODEL: SPL-6
△
DANGER
!
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.
Original

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPL-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AMGO SPL-6

Summary of Contents for AMGO SPL-6

  • Page 1 Original SINGLE POST PARKING LIFT MODEL: SPL-6 △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions Cargo Claims and safety precautions could result in serious If there is any missing or damaged injury or even death.

  • Page 2: Table Of Contents

    CONTENTS PROFILE AND WARRANTY ............... 2 SAFETY INSTRUCTION ..............4 I. PRODUCT FEATURES AND SPECIFICATIONS........5 II. INSTALLATION REQUIREMENT ............7 III. INSTALLATION STEPS ..............9 IV. EXPLODED VIEW................22 V. TEST RUN .................27 VI. OPERATION INSTRUCTIONS............28 VII. MAINTENANCE SCHEDULE............29 VIII. TROUBLE SHOOTING ..............30 IX. CAR LIFT SAFETY TIPS...............31 X.
  • Page 3 PROFILE This instruction manual is specially prepared for you. Your new lift is the product of over a decade of continuous research, testing and development. AMGO lifts are one of the best lifts you can purchase! Please make sure to read through this manual before operating the lift.

  • Page 4: Profile And Warranty

    SAFETY WARNING LABEL Fig. 1...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Ensure product installation complies with all applicable local regulations and rules, such as Occupational Safety and Health Administration regulations and electrical codes.

  • Page 6: Safety Instruction

    17. Stay alert. Use common sense to observe what you are doing and stay alert. 18. Check for damaged parts. Check for adjustments to moving parts, damage to parts, or anything that may affect their operation. Do not use the machine if the parts are damaged.

  • Page 7: Product Features And Specifications

    I. PRODUCT FEATURES AND SPECIFICATIONS Fig.2 Single-post Parking Lift MODEL SPL-6 · Specially designed for parking. · Dual safety device, no need air source, manual safety lock release. · Non slip lifting platform. · H-shaped lifting platform with reinforced column and base to provide excellent stability.
  • Page 8 Specification & Dimension Fig.3 MODEL SPL-6 SPECIFICATIONS Motor Overall Max. lock Max. lock Max. Width Lifting Lifting Max. height Overall Length height to height Min. Overall Model underneath Lifting Between Capacity Time underneath Height Incl. top of Height Width runway...

  • Page 9: Installation Requirement

    II. INSTALLATION REQUIREMENT A. Tools required √ √ Carpenter’s Chalk Hammer √ Screw sets √ Level Bar √ Tape Measure(295”) √English Spanner(12″) √Socket Head Wrench (3＃ 5＃ 8＃) √Pliers √ Wrench set：( 10 ..√Rotary Hammer Drill (Φ3/4) ＃ ＃ ＃...
  • Page 10 B.Storage and installation requirement 1. Store the equipment in a dry, non-moldy and non-flammable environment. 2. The lift is only approved for indoor installation and use. Outdoor installation is prohibited. 3. When installing the machine, take safety precautions according to the instructions to avoid device damage.

  • Page 11: Installation Steps

    4．Power. You need a 110VAC/60HZ or 220 VAC/60Hz, current 20A, with a cord larger than 12AWG. 5．Installations: AMGO car lifts are approved for indoor installation and use only. Outdoor installation is prohibited. 6．Floor. The lift should only be installed on a flat, level concrete surface and not on asphalt or any other type of flooring.
  • Page 12 Installing the lift on a surface with slopes more than 3° could lead to injury or even death. AMGO lifts are designed for installation on a flat and level surface only. (Defined as no more than 3/8 of an inch difference over the installation area). If the floor cannot be leveled, consider changing installation locations.
  • Page 13 Safety device cover, tire stop plate Parts box Arm connecting pin 3.Remove the bolts of upper package, move aside the platform at top layer, take out the parts inside the platform at second layer, and remove the package stand. Guide Drive-in Arms Arms...
  • Page 14 5. Open parts box, check the parts according to the parts box list. (See Fig.11) Fig.11 6. Check the parts of the parts bag according to the parts bag list. (See Fig. 12) Fig.12 C.Confirm the installation position and place the base onto it. (See Fig.13) Fig.13 D.Fix anchor bolts.
  • Page 15 Fig.14 E.Install column and connect the oil hose to cylinder. 1.Lay the column flat on the ground. (See Fig.15) Fig.15 2. Connecting oil hose to cylinder. (See Fig.16) A: Pull out the carriage around 8” from Pass the oil hose through the hole on the backside base plate.
  • Page 16 Position the column onto the base, align the mounting holes, and install with bolts. Check the column plumbness with level bar, adjust with shims if necessary. (See Fig.17) M20*50 Hex bolt with flat washer, lock washer 40~41 Fig.17 Adjust with 3/64”...
  • Page 17 platform connection to the carriage.(See Fig.19) Install M20*40 Hex bolt w/ flat washer, lock washer and nut After installation, grease the friction contact positions between column and slide block. Fig.19 G.Install power unit ,oil hoses and retainer 1.Install power unit, see fig 20 M8*25 Hex bolt w/ φ20*φ8*3 rubber ring and M8 Nylok...
  • Page 18 2. Install power unit, see fig 21 Install the 90° fitting to the power unit, then connect it with the oil hose that comes from the cylinder. 90°Fitting for power unit Fig.21 3. Install retainer, see fig 22. Install with M6*8 round head bolt w/ φ6 flat washer Fig.22 Note: Tighten the oil hose fitting and power unit fitting to avoid oil leakage.
  • Page 19 Note: To ensure the safety of operators, the lift must be grounded. Test the lift after installation to check if works fine. Single phase motor Connect the two hot wires of power supply respectively to the terminals of AC contactor marked L1 and L3 .
  • Page 20 J. Install platform Hoist the platforms onto the arms, align the mounting holes and connect with bolts (no need to tighten the bolts at this step, tighten them in turn after the bolts of the lateral sides are aligned with the holes.) Bolted with M12*35 Hex bolt w/ 2xflat washer, lock washer and nut.
  • Page 21 K.Install the drive-in ramps, tire stop plates and guide ramps. 1. Install drive-in ramps, tire stop plates. Install M16*30 hex bolts into the holes at both end of the platform , hang the drive-in ramps and tire stop plates onto the bolts, then tighten the bolts. Hang the slots of Install M16*30 hex bolts to Hang the slots of tire stop...
  • Page 22 Install guide ramps. Buckle the guide ramps directly into the base. See fig. 29 Buckle into the base Fig.29 L. Install fabric curtain cover . See fig 30. Follow the steps below to install the curtain Just assemble the nut to M6*95 Hook bolt, w/ flush with the hook bolt, φ6 flat washer and...
  • Page 23 Fix with M6*8 round head bolt with flat washer Pass the fabric curtain cover 4. Adjust the nuts until the fabric through the carriage to the bottom curtain cover is straight. mounting plate and fix with round head bolts. Fig.30 M.

  • Page 24: Exploded View

    IV. EXPLOEDED VIEW Fig.32...
  • Page 25 Parts List of SPL-6 Item Part# Description QTY. 1001085013 M12*30 hex bolt (w/ M12 Nylok nut) Top plate 11101013-01 Hook bolt M6*95 ( w/ φ6 flat washer, M6 Nylok 1101085015 Nut） 11101042 Fabric curtain cover L=2570 10207681 Chain pulley seat assy.
  • Page 26 Item Part# Description QTY. M8*25 hex bolt （w/ 8*20*3 rubber ring, M8 1001085009 nylok nut） 11203013 Connecting Bar 11209008 Safety device cover M6*8 round head bolt（w/ φ6 flat washer） 1001085016 Spring（120°） 10209007 11206002 Safety block pin 11203263 Safety device Snap pin（φ3.2） 10209012 10206003 Rubber sleeve of release handle...
  • Page 27 4.1 Exploded view of cylinder (10207010): Fig. 33 Item Part# Description QTY. Note 11207027 Piston rod 11207028 Piston 10206069 O-ring 10620053 Support ring 10620054 Y-ring 10630027 O-ring 10206071 Hex nut 11207029 Piston rod adjusting sleeve 10217078 Dust ring 10520058 O-ring 11207030 Head cap 10201034...
  • Page 28 4.2. Exploded view of chain pulley seat assy. (11207681): Fig.34 Item Part# Description QTY. 11207006 Pin for chain pulley Φ35*93 10420132A Bronze bush Φ41.2*Φ35.1*20 11530023 Flat washer Φ44*Φ35.5*2 11207007 Chain pulley Φ105*50 10430138 Socket bolt M6*16 10209149 Lock washer Φ6 10420045 Flat washer Φ6 11207693...

  • Page 29: Test Run

    Illustration of hydraulic Valve for hydraulic power unit Relief valve Oil return port Release valve Throttle Oil output port valve Handle for Oil output port release valve Check valve Fig. 35 V. TEST RUN 1. Adjust the lowering speed (Fig.28) If necessary, you can adjust the lower speed of the lift by turning the throttle valve clockwise to decrease it, or counterclockwise to increase the lower speed.

  • Page 30: Operation Instructions

    2. Test with load The load test should be conducted after the above adjustments have been completed. Run the lift at low level several times first, when there is no other abnormal phenomenon, run the whole process. Repeat the above adjustment if there is any abnormal phenomenon. Tips: There will be vibration during the first operation without load, load and run several times, the vibration will disappear naturally after the air in the hydraulic system is exhausted!

  • Page 31: Maintenance Schedule

    VII.MAINTENANCE SCHEDULE Monthly: 1. Tighten anchor bolts, torque of anchors is 150N.m; 2. Check all fittings, bolts and pins to ensure proper mounting; 3. Lubricate slide bock, chains with lubricant; 4. Make a visual inspection of all hydraulic hoses/lines for possible wear or leakage; 5.

  • Page 32: Trouble Shooting

    VIII. TROUBLE SHOOTING TROUBLE CAUSE REMEDY Start button does not work Replace Start button Wiring connections are not in good Repair all wiring connection condition Motor burned out Repair or replace motor AC contactor in damage Replace Motor does not run Repair or replace Release valve out of work Repair or replace...

  • Page 33: Car Lift Safety Tips

    IX. CAR LIFT SAFETY TIPS Post this safety tips in a place that will always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use original equipment parts to repair;...
  • Page 34 No：72210502 Date：2023/09...
