Summary of Contents for Waldorf Bold PCB8140E-7
- Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Electric Pasta Cooker PC8 1 4 0 E PCL 8 1 40 E PCB 8 1 40 E PCL B8 1 40 E PC8 1 4 0 E-7...
- Page 2 Moffat Limited Rolleston 7675 New Zealand AUSTRALIA Moffat Pty Limited E.Mail: vsales@moffat.com.au Main Office: (tel): +61 (03) 9518 3888 (fax): +61 (03 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA Serve Canada...
- Page 3 PC(L)(B)8140E ELECTRIC PASTA COOKER - (Single Tank - 40 Ltr) Model Numbers Covered in this Specification General Optional Accessories Electrical Supply Requirements Electrical Connection Water Supply Requirements Installation Requirements Unpacking Location Clearances Assembly Electrical Connection Water Connection Drainage Connection Commissioning Operation Guide Description of Controls Before Use...
- Page 4 We are confident that you will be delighted with your WALDORF Electric Pasta Cooker and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new WALDORF Appliance, there are two important things you can do.
- Page 5 PC[1]8140E PASTA COOKER (10.5 kW). PC[1]8140E-7 PASTA COOKER (7.0 kW). NOTE: [1]: - Model Options; - Standard. - Low Back. - Bold Front. - Low Back & Bold Front. A commercial heavy duty, electric, high performance Pasta Cooker designed for cooking in a commercial high production output site.
- Page 7 Installation shall comply with local, electrical health and safety requirements. Waldorf Electric Pasta Cookers are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering electrical, fire safety and health and safety.
- Page 8 This model is delivered completely assembled. Ensure that the adjustable feet are securely attached. NOTE: This appliance is fitted with adjustable feet to enable the appliance to be positioned securely and level. This should be carried out on completion of the electrical connection.
- Page 9 The water is drained from the appliance by means of a valve located behind the front access door. A waste water tundish must be fitted below the appliance drain outlet. This should be a minimum of 127mm (5”) major diameter. ...
- Page 10 Waldorf Pasta Cookers have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can produce a poor quality product. To use this pasta cooker correctly please read the following sections carefully;...
- Page 11 REAT CARE MUST BE TAKEN BY THE OPERATOR TO USE THE PASTA COOKER SAFELY TO GUARD AGAINST THE RISK OF INJURY AND FIRE DO NOT LEAVE THE PASTA COOKER UNATTENDED DURING OPERATION DO NOT OVER FILL THE WATER IN THE PASTA COOKER ABOVE THE UPPER FILL LEVEL MARK ...
- Page 12 Ensure that the pasta cooker tank is full of water to the upper fill mark. Check that the electrical supply is turned ‘On’ at the mains supply. Select the ‘power’ level on the element control knob to either Simmer / Boil / or Rapid as required. The ‘green’...
- Page 13 DO NOT USE FLAMMIBLE SOLVENTS AND CLEANING AIDS ON OR IN CLOSE PROXIMITY TO THE PASTA COOKER HOT. WHILST THE COOKER IS STILL Clean the pasta cooker regularly. A clean pasta cooker looks better, will last longer and will perform better.
- Page 14 Locking Slide locked position Locking Slide unlocked position Fig 3 Fig 4 OT WATER WILL SCALD DO NOT RUSH THIS JOB Clean the interior of the pan regularly after each use. Do not use wire brushes on the pan. Clean using a mild detergent and a hot water solution using soft cloth or a soft bristled brush.
-
Page 15: Stainless Steel Surfaces
O NOT ATTEMPT TO MOVE THE ASTA OOKER WHILST THE COOKER IS FULL OF WATER EFORE ATTEMPTING TO MOVE THE ASTA OOKER ENSURE THAT ALL THE WATER HAS BEEN DRAINED FROM THE TANK EFER TO THE INFORMATION ON THE PREVIOUS PAGE ON HOW TO DRAIN THE WATER FROM THE ASTA OOKER... - Page 16 This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.
-
Page 17: Electrical Supply Requirements
PC8140E Pasta Cooker ELEMENTS 2.3KW each (PC8140-7) 3.5KW each (PC8140) Electrical Supply Requirements PC8140E 10.5 kW 3P+N+E, L1=L2=L3 = 15A @ 240V 1P+N+E, 44A @ 240V PC8140E-7 7.0 kW 1P+N+E, 30A @ 240V 3P+N+E, L1=L2=L3 = 10A @ 240V... -
Page 18: Replacement Parts List
Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the front cover of this manual).
