- Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Range Static Oven RN8410G RNL8410G RN8820G RNL8820G Date Purchased...
- Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA...
-
Page 3: Table Of Contents
Contents Waldorf Gas Static Oven Range RN(L)8410G Gas Range Static Oven - 600 mm. RN(L)8820G Gas Range Double Static Oven - 1200 mm. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions .................... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your WALDORF GAS RANGE STATIC OVEN and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf appliance, there are two important things you can do. -
Page 5: Specification
Specifications Model Numbers Covered in this Specification RN[1]8410G [2] Gas Range Static Oven + 4 Open Burners. RN[1]8413G [2] Gas Range Static Oven + 2 Open Burners + 300 mm Griddle. RN[1]8416G [2] Gas Range Static Oven + 600 mm Griddle. RN[1]8820G [2] Gas Range Double Static Oven + 8 Open Burners. -
Page 6: Gas Supply Requirements
Specifications Gas Supply Requirements - Non CE Only (Australia / New Zealand): Natural Gas LP Gas (Propane) Input Rate (N.H.G.C.) 28 MJ/hr 28 MJ/hr - each Open Burner (26,538 Btu/hr) (26,538 Btu/hr) 21 MJ/hr 21 MJ/hr - each 300 mm Griddle Section (19,900 Btu/hr) (19,900 Btu/hr) 24 MJ/hr... -
Page 7: Dimensions
Dimensions RN(L)8410G Gas Cooktop Options RN(L)8413G RN(L)8410G RN(L)8416G... - Page 8 Dimensions RN(L)8820G Gas Cooktop Options RN(L)8820G RN(L)8823G RN(L)8826G RN(L)8829G...
-
Page 9: Installation
Waldorf Ovens are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety. -
Page 10: Clearances
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN AUTHORISED PERSON. Waldorf Ranges do not require an electrical connection, as they function totally on gas supply only. It is essential that gas supply is correct for appliance being installed and that adequate supply pressure and volume are available. -
Page 11: Commissioning
Installation NOTE: Gas pressure regulator provided with this appliance is convertible between Natural Gas and LPG as shown in ‘Gas Conversion Section’ in this manual. Ensure regulator is converted to correct gas type that appliance will operate on. Regulator outlet pressure is fixed ex-factory for gas type that regulator is converted to and it is NOT to be adjusted. -
Page 12: Operation
/ operator. Waldorf appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. -
Page 13: Open Burners
Operation Open Burners NOTE: Only cooking pans from size Ø 150 mm to Ø 420 mm are suitable fo use on these open burners. Flame Failure Option (F-Models) Lighting the Open Burners Flame Failure Protection is incorporated for each burner by way of a thermo-electric system which will shut off gas supply to that burner if burner goes out, so that un-burnt gas is not expelled. -
Page 14: Griddles
Operation Griddle Caution Griddle plate temperature reaches over 300°C in hottest points during normal operation at 'Full Flame' setting. These griddles are fitted with a pilot as a standard option and Flame Failure Protection, which is incorporated by way of a thermo-electric system for each main burner. Flame Failure Protection will shut off gas supply to burner in the event that pilot for that burner goes out, so that un-burnt gas is not This is an important safety feature which is slowly becoming law throughout the expelled. -
Page 15: Oven Pilot Ignition
Operation Oven Pilot Ignition ! IMPORTANT DO NOT USE aluminium foil or trays directly on cast iron sole plate(s). NEVER block or cover openings on each side of sole plate(s). Open oven door. Depress thermostat control knob and Pilot Burner rotate anti-clockwise to ‘PILOT’... -
Page 16: Cleaning And Maintenance
Cleaning and Maintenance General Caution Always turn off the gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean the range regularly. A clean range looks better, will last longer and will perform better. Carbonised grease on surface or between trivets, griddle plates will hinder transfer of heat from cooking surface to food. -
Page 17: Daily Cleaning
Cleaning and Maintenance Daily Cleaning Grease / spill trays should be checked and emptied frequently to prevent overflow and spillage. Remove grease drawer while still warm so that grease is in a liquid state. Empty any grease from drawer and wash thoroughly in same manner as any cooking utensil. Remove burner caps and bases, trivets and thoroughly clean splash back, interior and exterior surfaces of range with hot water, a detergent solution and a soft scrubbing brush. - Page 18 Cleaning and Maintenance Trivets and Burners Burner Cap a. Remove trivets from top of appliance, taking note that trivets are manufactured with a lip on one edge, lip must always be fitted to outer edge (front and back) of range. (See Fig 10).
-
Page 19: Periodic Maintenance
Cleaning and Maintenance Notice Lip on NOTE: It is imperative that trivet supports are correctly Trivet Edge re-fitted to appliance to ensure that trivets locate correctly and sit flush and level. NOTE that trivet support front end side rail profiles are different at either side (Refer to Fig 6) and only one of side rails seat into cut-out in range, whereas rear end of trivet support side rail profiles are the same and have 2... -
Page 20: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 21: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure Caution Ensure that the Appliance is isolated from the gas supply before commencing servicing. NOTE: These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. ... - Page 22 Gas Conversion and Specifications Piezo Igniter Griddle Pilot Supply Tube Carry out the following:- Remove griddle plate section and heat shield. Remove main burner. Disconnect piezo igniter from mounting bracket. (For access purposes). Pilot Burner Disconnect pilot supply tube from pilot burner to access pilot injector.
-
Page 23: Gas Specifications
Gas Conversion and Specifications Remove pilot and main injectors and replace with correct size injectors as shown in ‘Gas Specifications Tables’ at end of this section. Refit the following:- Re-connect pilot supply tube to pilot burner. Refit main burner and sole plate(s). ... -
Page 24: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia / New Zealand Only: Natural. Gas (G20) Propane (G31) Main Burner Injectors Ø 2.45 mm Ø 1.50 mm Open Burners Pilot Burner ('PF' Option Only) 0.30 0.20 Main Burner Ø 2.10 mm Ø... -
Page 25: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for servicing and repair of this appliance. Instructions supplied with parts should be followed when replacing components. further information servicing instructions, contact your nearest authorized service branch (contact details are as shown on reverse of front cover of this manual). - Page 26 228704 Door Spring Kit (Includes 2 Springs). General 227015 Pot Stand / Trivet. 228882 Spill Tray 600 mm (RN8410G / RN8820G Series). 227850 Adjustable Leg (150 mm). 229674 Rear Roller Assy. Gas Conversion Kits Gas Type to Convert to Models...
