Hardware Installation and Reference Guide
1.3

Technical Specifications

Table 1-5 Specifications
Radio Design
Protocol and
Standard
Operating
Band
Antenna
Spatial Streams
Data Rate
Modulation
Receive
Sensitivity
2.4 GHz and 5 GHz dual-radio dual-stream
Supports both 802.11ac wave2/wave1 and 802.11a/b/g/n
standards for simultaneous operation
802.11b/g/n: 2.4 GHz-2.4835 GHz
802.11a/n/ac: 5.150 GHz-5.350 GHz, 5.470 GHz-5.725 GHz, 5.725
GHz-5.850 GHz
Built-in omni-directional onboard antenna designed for low
radiation emissions (2.4 GHz: 3.82 dBi; 5 GHz: 4.10 dBi)
Note
The peak gain mentioned above refers to the gain of a
single antenna.
2.4 GHz: 2x2 MIMO
5 GHz: 2x2 MIMO
2.4 GHz: 400 Mbps
5 GHz: 867 Mbps
Combined: 1267 Mbps
DBPSK/DQPSK/CCK(DSSS)/BPSK/QPSK/16QAM/64QAM/256QAM
802.11b: -91 dBm (1 Mbps), -88 dBm (5 Mbps), and -85 dBm (11
Mbps)
802.11a/g: -89 dBm (6 Mbps), -80 dBm (24 Mbps), -76 dBm (36
Mbps), and -71 dBm (54 Mbps)
802.11n: -83 dBm (MCS 0), -65 dBm (MCS 7), -83 dBm (MCS 8), and
-65 dBm (MCS 15)
802.11ac: HT20: -83 dBm (MCS 0), and -57dBm (MCS 9)
802.11ac: HT40: -79 dBm (MCS 0), and -57 dBm (MCS 9)
4
Product Overview
