Hardware Installation and Reference Guide
Max. Transmit
Power
Power
Increment
Dimensions (W
× D × H)
Weight
Service Ports
Management
Port
Status LED
Input Power
Supply
Max. Power
Consumption
Bluetooth 5.0
Environment
802.11ac: HT80: -76 dBm (MCS 0), and -51dBm (MCS 9)
2.4 GHz ≤ 20 dBm
5 GHz ≤ 30 dBm
Note
The transmitted power may vary based on local laws and
regulations.
1 dBm
86 mm x 86 mm x 42.4 mm (9.06 in. x 9.06 in. x 1.93 in., excluding
the mounting bracket)
AP weight: 0.14 kg
Front: 1 x 10/100/1000Base-T Ethernet downlink port
Rear: 1 x 10/100/1000Base-T Ethernet uplink port, powered by
the power sourcing equipment (PSE)
N/A
1 x system status LED
802.3at/bt-compliant PoE
≤ 9 W
Not supported
Operating temperature: 0°C to 40°C (32°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Operating humidity: 5% to 95% (non-condensing)
Storage humidity: 5% to 95% (non-condensing)
5
Product Overview
