Communication Ports
The RUGGEDCOM RSG907R can be equipped with various types of communication
ports to enhance its abilities and performance.
1
2
3
Ports A and B
1
Port 5
2
Ports 1 to 4
3
Figure 4.1
4.1
Redundant Network Access (RNA) Ports
The RUGGEDCOM RSG907R features three dedicated Small Form-factor Pluggable
(SFP) transceiver sockets for PRP/HSR applications:
RUGGEDCOM RSG907R
Installation Manual, 02/2021, C79000-G8976-1387-12
All manuals and user guides at all-guidesbox.com
Port Assignment
Port
A/B
SFP Transceiver (1000Base-SX/LX)
5
SFP Transceivers (1000Base-SX/LX)
1 to 4
Fiber Optic (100Base-FX) Ethernet Ports
Type
4
27
