Communication Ports

The RUGGEDCOM RS969 can be equipped with various types of communication ports
to enhance its abilities and performance. To determine which ports are equipped on
the device, refer to the factory data file available through RUGGEDCOM RS969. For
more information on how to access the factory data file, refer to the "RUGGEDCOM
RS969 User Guide" for the RUGGEDCOM RS969.
Each communication port type has a specific place in the RUGGEDCOM RS969
chassis.
1
1
2
Figure 4.1
RUGGEDCOM RS969
Equipment Manual, 10/2023, C79000-G8976-1038-05
M12 D-Coded Copper Ethernet Ports
Fiber Optic Ethernet Ports
Port Assignment (M12 Connectors Shown)
2
4
23
