Operating Instructions
FTZ-UNI-15
5.3

Gripping ranges

1 2 3
Adjustment of the gripping area through the
positions of the adjustable holes (symmetrical):
Pos.1 + Pos.1
(right) (left)
Pos.2 + Pos.2
(right) (left)
Pos.3 + Pos.3
(right)
Pos.4 + Pos.4
(right)
Pos.5 + Pos.5
(right)
Pos.6 + Pos.6
(right)
Pos.7 + Pos.7
(right) (left)
Pos.8 + Pos.8
(right)
Pos.9 + Pos.9
(right)
14 / 19
4 5 6 7
(left)
(left)
(left)
(left)
(left)
(left)
Adjustments
8 9 9 8
Possible gripping areas for gripping goods
(product dimension):
from ~ 0
from ~ 80
from ~ 160
from ~ 270
from ~ 350
from ~ 430
from ~ 500
from ~ 570
from ~ 640
V7
7 6 5 4 3
to ~ 80 mm
to ~ 160 mm
to ~ 270 mm
to ~ 350 mm
to ~ 430 mm
to ~ 500 mm
to ~ 570 mm
to ~ 640 mm
to ~ 730 mm
2 1
