User Manual
Widescreen LCD Display -
4:3 LCD Display -
19", 22" size
Rackmount display :
RP-W822
RP-W719
15", 17", 19", 20" size
Rackmount display :
RP-615 / RP-717 / RP-819 / RP-920
SP-717 / SP-819 / SP-920
1U Display drawer :
RP-115 / RP-117 / RP-119 / RP-120
RP-1415 / RP-1417 / RP-1419 ( short-depth )
1U Display drawer :
SP-117 / SP-119 / SP-120
( designed for SUN Solaris )
Options :
- BNC + S-Video
- DVI
- Audio
1U Display drawer :
RP-W119
- Touchscreen
- DC power
- Quad Display
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CyberView RP-W822
Summary of Contents for CyberView RP-W822
- Page 1 User Manual Widescreen LCD Display - 19", 22" size 1U Display drawer : Rackmount display : RP-W119 RP-W822 RP-W719 4:3 LCD Display - 15", 17", 19", 20" size Rackmount display : RP-615 / RP-717 / RP-819 / RP-920 SP-717 / SP-819 / SP-920...
-
Page 2: Table Of Contents
Important Safeguards............1 Regulatory Notice...............2 Before Installation...............3 Unpacking................3 Optional Accessories............3 Peripheral Products............4 Part 1 Widescreen LCD Display Chapter 2 RP-W719 & RP-W822 Package Contents...............5 Structure Diagram...............6 Installation...............7-8 Connection.................9 Chapter 3 RP-W119 Package Contents.............10 Structure Diagram.............11 How to Install “One Man” Installation Slides....12-13 How to Use the Slides............14... - Page 3 Part 2 4:3 LCD Display Chapter 6 RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Package Contents............26 Structure Diagram............27 Installation..............28-29 Connection...............30 Chapter 7 RP-120 SP-120 RP-115, RP-117 & RP-119 SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 Package Contents.............31 Structure Diagram.............32 How to Install “One Man”...
-
Page 4: Getting Started 1.1 Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 5: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice. -
Page 6: Before Installation
Chapter 1 1.3 Before Installation ■ It is very important to locate the Rackmount LCD Drawer / Display in a suitable environment. ■ The surface for placing and fi xing the Rackmount LCD Drawer / Display should be stable and level or mounted into a suitable cabinet. -
Page 7: Peripheral Products
Chapter 1 1.6 Peripheral Products Item Model No. Description MU-1602 / MU-1603 / MU-1604 Matrix Cat6 16 port KVM MU-IP1613 / MU-IP1614 / MU-IP1624 Matrix IP Cat6 16 port KVM Matrix Cat6 KVM MU-3202 / MU-3203 / MU-3204 Matrix Cat6 32 port KVM MU-IP3213 / MU-IP3214 / MU-IP3224 Matrix IP Cat6 32 port KVM M-802 / M-803 / M-804... -
Page 8: Rp-W719 & Rp-W822
Chapter 2 2.1 Package Contents RP-W719 & RP-W822 Rackmount LCD display x 1 pc User manual x 1 pc 6’ VGA cable (male to male) x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc M3.2*4.5mm screw x 4 pcs... -
Page 9: Structure Diagram
Chapter 2 2.2 Structure Diagram RP-W719 & RP-W822 Power adapter Front view Rear view Power cord LCD interchangeable module kit LCD membrane Power adapter bracket Power adapter bracket installation M3.2*4.5mm screw x 4 pcs... - Page 10 Chapter 2 2.3 Installation RP-W719 ■ Install each screw shown in Figure 1. Figure 1. ■ Fix the LCD into the rack. * M6 screws are not provided. Figure 2.
-
Page 11: Installation
Chapter 2 2.3 Installation RP-W822 Figure 3. Figure 4. ■ ■ Install each screw shown in Figure 3. Insert the upper part of the LCD display to the rack shown in Figure 4. * M6 screws are not provided. Figure 5. -
Page 12: Connection
Chapter 2 2.4 Connection RP-W719 & RP-W822 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 13: Rp-W119
Chapter 3 3.1 Package Contents RP-W119 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 6 pcs Cup washer x 8 pcs P.10... -
Page 14: Structure Diagram
Chapter 3 3.2 Structure Diagram RP-W119 LCD interchangeable module kit Carry handle to release the 2-pt lock “One Man” Installation Slide 2-point lock LCD membrane P.11... -
Page 15: How To Install "One Man" Installation Slides
Chapter 3 3.3 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■... - Page 16 Chapter 3 3.3 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■ Tighten all 8 pcs of M6 screw to complete the installation.
-
Page 17: How To Use The Slides
Chapter 3 3.4 How to Use the Slides RP-W119 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 7). Figure 7. ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock. (shown in Figure 8). -
Page 18: Connection
Chapter 3 3.5 Connection RP-W119 Power Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 19: On-Screen Display Operation
Chapter 4 4.1 On-screen Display Operation RP-W719 & RP-W822 LCD membrane RP-W119 LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control... -
Page 20: On-Screen Menu
Chapter 4 4.2 On-screen Menu RP-W719, RP-W822 & RP-W119 OSD Confi guration Page Image: To enter into the brightness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock... -
Page 21: Dvi-D Option
Chapter 5 5.1 DVI-D Option RP-W719 & RP-W822 DVI-D Power RP-W119 Power DVI-D Remarks ■ Package includes 1 x 6ft DVI-D cable P.18... -
Page 22: Bnc + S-Video Option
Chapter 5 5.2 BNC + S-Video Option RP-W719 & RP-W822 S-Video BNC Power RP-W119 Power S-Video BNC Remarks ■ Package includes 1 x 6ft S-Video cable P.19... -
Page 23: Audio Option
Chapter 5 5.3 Audio Option RP-W719 & RP-W822 Speaker Audio Power RP-W119 Speaker Power Audio Remarks: ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.20... -
Page 24: Touchscreen Options
Chapter 5 5.4 Touchscreen Options RP-W719 & RP-W822 USB interface Power Serial interface Serial Power P.21... - Page 25 Chapter 5 5.4 Touchscreen Options e-Resistive Model -19WTRB / -19WTRS -22WTRB / -22WTRS Screen size 19" wide 22" wide Interface USB / serial Optical transmittance 80% ± 3% Surface hardness ≥3H (JIS K5400) Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux e-Capacitive Model -19WTCB / -19WTCS...
-
Page 26: Front Nema / Ip65 Option
Chapter 5 5.5 Front NEMA 4 / IP65 Option RP-W719 & RP-W822 Rear case LCD panel 4mm protective glass (Front NEMA 4 / IP65 protection) Aluminum front panel Remarks ■ 4mm thickness of protective glass is not toughened one, please handle it carefully. -
Page 27: Quad Display Option
Chapter 5 5.6 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System... -
Page 28: Dc Power Options
Chapter 5 5.7 DC Power Options RP-W719 & RP-W822 DC Power input RP-W119 DC Power input Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load... -
Page 29: Rp-615, Rp-717, Rp-819 & Rp-920 Sp-717, Sp-819 & Sp-920 6.1 Package Contents
Chapter 6 6.1 Package Contents RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Rackmount LCD display x 1 pc User manual x 1 pc 6’ VGA cable (male to male) x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc M3.2*4.5mm screw x 4 pcs Power adapter bracket x 1 pc P.26... -
Page 30: Structure Diagram
Chapter 6 6.2 Structure Diagram RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Power adapter Front view Rear view For 15", 17” & 19” LCD Power cord LCD interchangeable module kit LCD membrane Power adapter bracket Power adapter bracket installation M3.2*4.5mm screw x 4 pcs P.27... - Page 31 Chapter 6 6.3 Installation RP-615, RP-717 & RP-819 SP-717 & SP-819 ■ Install each screw shown in Figure 10. Figure 10. ■ Fix the LCD into the rack. * M6 screws are not provided. Figure 11. P.28...
- Page 32 Chapter 6 6.3 Installation RP-920 & SP-920 ■ Install each screw shown in Figure 12. Figure 12. ■ Fix the LCD into the rack. * M6 screws are not provided. Figure 13. P.29...
-
Page 33: Connection
Chapter 6 6.4 Connection RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 DB-15 VGA female connector Power input Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 34: Rp-115, Rp-117 & Rp-119 Sp-117 & Sp-119 Rp-1415, Rp-1417 & Rp-1419 7.1 Package Contents
Chapter 7 7.1 Package Contents RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Auto switch power adapter ( for external power version) x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs... -
Page 35: Structure Diagram
Chapter 7 7.2 Structure Diagram RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 LCD interchangeable module kit Carry handle to release the 2-pt lock “One Man” Installation Slide 2-point lock LCD membrane P.32... -
Page 36: How To Install "One Man" Installation Slides
Chapter 7 7.3 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■... - Page 37 Chapter 7 7.3 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
-
Page 38: How To Use The Slides
Chapter 7 7.4 How to Use the Slides RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 14). Figure 14. ■... -
Page 39: Connection
Chapter 7 7.5 Connection RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 Internal power version Power External power version ( For short depth version - RP-1415 / 1417 / 1419 ) Caution : The Rackmount LCD Drawer & Display are hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable. -
Page 40: On-Screen Display Operation
Chapter 8 8.1 On-screen Display Operation RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 15" LCD membrane 17", 19" & 20" LCD membrane Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button... -
Page 41: On-Screen Menu
Chapter 8 8.2 On-screen Menu RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 OSD Confi guration Page Image: To enter into the brightness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: To enter into the colour, tint, sharpness, noise reduction, DCDi and... -
Page 42: Dvi-D Option
Chapter 9 9.1 DVI-D Option RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 DVI-D Power Remarks ■ Package includes 1 x 6ft DVI-D cable RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 Internal power version DVI-D External power version ( For short depth version - RP-1415 / 1417 / 1419 ) -
Page 43: Bnc + S-Video Option
Chapter 9 9.2 BNC + S-Video Option RP-615, RP-717, RP-819 & RP-920 S-Video BNC Power RP-120 RP-115, RP-117 & RP-119 RP-1415, RP-1417 & RP-1419 Internal power version S-Video BNC External power version ( For short depth version - RP-1415 / 1417 / 1419 ) Remarks ■... -
Page 44: Audio Option
Chapter 9 9.3 Audio Option RP-615, RP-717, RP-819 & RP-920 Speaker Audio Power Remarks ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.41... - Page 45 Chapter 9 9.3 Audio Option RP-120 RP-115, RP-117 & RP-119 RP-1415, RP-1417 & RP-1419 Speaker Internal power version Power Audio External power version ( For short depth version - RP-1415 / 1417 / 1419 ) Remarks: ■ Audio input is 35mm audio plug ■...
-
Page 46: Touchscreen Options
Chapter 9 9.4 Touchscreen Options RP-615, RP-717, RP-819 & RP-920 USB interface Power Serial interface Serial Power RP-120 RP-115, RP-117 & RP-119 RP-1415, RP-1417 & RP-1419 USB interface Power Internal power version ( For short depth version - RP-1415 / 1417 / 1419 ) External power version Serial interface Power... - Page 47 Chapter 9 9.4 Touchscreen Options e-Resistive Model -15TRB / -15TRS -17TRB / -17TRS -19TRB / -19TRS -20TRB / -20TRS Screen size 15" 17" 19" 20" Interface USB / serial Optical transmittance 80% ± 3% Surface hardness ≥3H (JIS K5400) Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux e-Capacitive Model...
-
Page 48: Front Nema / Ip65 Option
Chapter 9 9.5 Front NEMA 4 / IP65 Option RP-615, RP-717, RP-819 & RP-920 Rear case LCD panel 4mm protective glass (Front NEMA 4 / IP65 protection) Aluminum front panel Remarks ■ 4mm thickness of protective glass is not toughened one, please handle it carefully. P.45... -
Page 49: Quad Display Option
Chapter 9 9.6 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System... -
Page 50: Dc Power Options
Chapter 9 9.7 DC Power Options RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 DC Power input RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 DC Power input Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range:... -
Page 51: Chapter 10 Lcd Specifi Cations
Chapter 10 10.1 LCD Specifi cations RP-W719, RP-W822 & RP-W119 Item Description LCD Manufacturer RP-W119 RP-W719 RP-W822 Diagonal Size Wide 19" TFT Wide 19" TFT Wide 22" TFT Max. Resolution 1440 x 990 1440 x 990 1680 x 1050 Brightness (cd/m²) Color Support 16.7 M... - Page 52 Chapter 10 10.1 LCD Specifi cations RP-120 RP-115, RP-117, RP-119 RP-1415, RP-1417 & RP-1419 RP-615, RP-717, RP-819 & RP-920 Item Description LCD Manufacturer Diagonal Size 15" TFT 17" TFT 19" TFT 20" TFT Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024 1600 x 1200 Brightness (cd/m²)
- Page 53 Chapter 10 10.1 LCD Specifi cations SP-120 SP-117 & SP-119 SP-717, SP-819 & SP-920 Item Description Form Factor 1U rack mounting on slide-out rails Diagonal Size 17" TFT 19" TFT 20" TFT 1152 x 900 (Direct) 1152 x 900 (Direct) 1152 x 900 (Direct) Resolution 1280 x 1024 (Native)
-
Page 54: Chapter 11 Troubleshooting
Chapter 11 11.1 Troubleshooting 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by the display card in your computer. -
Page 55: Chapter 12 Dimensions
Chapter 12 12.1 Dimensions RP-W719, RP-W822 & RP-W119 RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 57.5 mm... - Page 56 Chapter 12 12.1 Dimensions RP-120 SP-120 RP-115, RP-117, RP-119 SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 442 x 650 x 44 mm 581 x 755 x 172 mm 14 kg 19 kg...
