User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-SP-717-Q420V1
dedicated KVM switch and rackmount screen technology
17" / 19" / 20" LCD 1152 x 900 Native Resolution
SP-717 / SP-819 / SP-920
SUN Rackmount Display Panel
Options :
- DC power
www.austin-hughes.com
751
Advertisement
Related Manuals for CyberView SP-717
Summary of Contents for CyberView SP-717
- Page 1 KVM switch and rackmount screen technology User Manual 17” / 19” / 20” LCD 1152 x 900 Native Resolution SP-717 / SP-819 / SP-920 SUN Rackmount Display Panel Options : - DC power Designed and manufactured by Austin Hughes UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
- Page 3 Contents SP-717 / 819 / 920 < Part. 1 > SP-717 / SP-819 / SP-920 Package Content Structure Diagram & Dimension P.1 - 4 Installation < Part. 2 > Specifi cations / OSD / Remote Controller Product Specifi cations P.6 - 9 On-screen Display Operation ( OSD ) P.10 - 11...
- Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
- Page 5 < Part 1 > < 1.1 > Package Content SP-717 / 819 / 920 SP-717 or SP-819 or SP-920 X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 < 1.2 > Structure Diagram SP-717...
- Page 6 < 1.2 > Dimension - SP-717 Front View Side View SP-717 UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 54.2 x 310 mm 529 x 124 x 495 mm 6.1 kg...
- Page 7 < 1.2 > Dimension - SP-819 SP-717 / 819 / 920 Front View Side View SP-819 UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 53.3 x 354.8 mm...
- Page 8 (W x D x H) Weight 480 x 63.5 x 399 mm 583 x 124 x 529 mm 8.5 kg 11 kg SP-920 18.9 x 2.5 x 15.7 inch 23 x 4.9 x 20.8 inch 19 lb 24 lb UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
- Page 9 < 1.3 > Installation SP-717 / 819 / 920 SP-717 / SP-819 Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided.
- Page 10 < Part 2 > < 2.1 > Product Specifi cations - SP-717 / SP-819 SP-717 SP-819 Panel Manufacturer Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD 1152 x 900 ( Direct ) 1152 x 900 ( Direct )
- Page 11 SP-717 / 819 / 920 Physical SP-717 SP-819 Specifi cation Product ( W x D x H ) 480 x 54.2 x 310 mm 480 x 53.3 x 354.8 mm 18.9 x 2.1 x 12.2 inch 18.9 x 2.1 x 14 inch...
- Page 12 Environmental Operating Temperature 0 to 55°C degree Humidity 20~90%, non-condensing Conditions Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
- Page 13 SP-717 / 819 / 920 Physical Product ( W x D x H ) 480 x 63.5 x 399 mm Specifi cation 18.9 x 2.5 x 15.7 inch Packing ( W x D x H ) 583 x 124 x 529 mm 23 x 4.9 x 20.8 inch...
- Page 14 (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital & video connection (DVI-D and video options only) SP-717 / SP-920 Membrane Switch Function Turn the monitor on or off Display the OSD menu...
- Page 15 < 2.2 > On-screen Display Operation ( OSD ) SP-717 / 819 / 920 OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock...
- Page 16 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2020 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-SP-717-Q420V1 www.austin-hughes.com...
