User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-RP-F617-Q220V1
dedicated KVM switch and rackmount screen technology
17" FHD 1080p LCD
RP-F617
6U Rackmount Display Panel
Options :
- SDI / MCS
- HDMI / DP / Audio
- Touchscreen / DC power
- MIL-type or lockable connector
www.austin-hughes.com
751
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CyberView RP-F617
Summary of Contents for CyberView RP-F617
- Page 1 KVM switch and rackmount screen technology User Manual 17” FHD 1080p LCD RP-F617 6U Rackmount Display Panel Options : - SDI / MCS - HDMI / DP / Audio - Touchscreen / DC power - MIL-type or lockable connector...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-RP-F617-Q220V1 www.austin-hughes.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > RP-F617 Package Content Structure Diagram & Dimension Installation < Part. 2 > Specifi cations / OSD / Remote Controller Product Specifi cations On-screen Display Operation ( OSD ) < Part. 3 > Options 3G / HD / SD-SDI Broadcast-grade input P.10... - Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-RP-F617-Q220V1 www.austin-hughes.com...
-
Page 5: Rp-F617
< Part 1 > < 1.1 > Package Content RP-F617 RP-F617 unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 < 1.2 > Structure Diagram Front view Power adapter Rear view... - Page 6 (W x D x H) Weight 480 x 48 x 266 mm 529 x 124 x 451 mm 4.5 kg 6 kg RP-F617 18.9 x 1.9 x 10.5 inch 20.8 x 4.9 x 17.8 inch 9.9 lb 13.2 lb UM-CV-751-RP-F617-Q220V1...
-
Page 7: Installation
< 1.3 > Installation RP-F617 Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided. Step ■ Fix the LCD into the rack. -
Page 8: Product Specifi Cations
Power Supply Range Auto-sensing 100 to 240VAC, 50 / 60Hz Power Consumption Screen ON Max. 14W Power saving mode Max. 2W Power button OFF Max. 1W Regulatory Safety FCC & CE certifi ed Environmental RoHS2 & REACH compliant UM-CV-751-RP-F617-Q220V1 www.austin-hughes.com... - Page 9 RP-F617 Environmental Operating Temperature 0 to 55°C degree Humidity 20~90%, non-condensing Conditions Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical...
- Page 10 Intentionally Left Blank UM-CV-751-RP-F617-Q220V1 www.austin-hughes.com...
- Page 11 < 2.2 > On-screen Display Operation ( OSD ) RP-F617 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control...
-
Page 12: On-Screen Display Operation ( Osd )
: Align the screen image left or right OSD V-Position : Align the screen image up or down OSD time out : Adjust the screen timeout OSD transparency : Adjust the screen transparency OSD rotation : Rotate the screen - 90° / 180° / 270° UM-CV-751-RP-F617-Q220V1 www.austin-hughes.com... - Page 13 RP-F617 Reset Reset : Return the adjustment back to factory setting MISC Signal source : Select the signal source - DP / HDMI1 / HDMI2 Mute : Turn off the surrounding sound Audio in : Auto / Line in / DP...
- Page 14 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 15 LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with CyberView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 16 ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display size to fi x the issue. UM-CV-751-RP-F617-Q220V1 P.12 www.austin-hughes.com...
- Page 17 < 3.4 > Options : Touchscreen & driver RP-F617 F17" USB Touchscreen Specifi cation Model e-Resistive Technology 5-Wire Resistive Touch Point Single Method Stylus or Finger Activation Force ≤ 50g / Stylus=R0.8 Durability 10 million touches Response Time 15 ms Optical Transmittance 80% ±...
- Page 18 1220 mA 749 mA Output rating Output voltage: 12-Volt 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A 6.25A Effi ciency For DC power option : ( 1 ) If the unit with LCD, earthing may be required UM-CV-751-RP-F617-Q220V1 P.14 www.austin-hughes.com...
-
Page 19: Mil-Type Or Lockable Connector
< 3.6 > Options : MIL-type or Lockable Connector RP-F617 Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl... - Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2020 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-RP-F617-Q220V1 P.16 www.austin-hughes.com...
