Focus mode
Select the focus mode.
Select Auto to adjust the focus automatically.
Select Manual to adjust the focus manually using the
NEAR and FAR buttons on the main viewer page. If you
click the ONE PUSH AF button, the focus is adjusted
instantly. (See “Focusing” on page 12.)
White balance mode
Select the white balance mode.
You can select from among Auto, Indoor, Outdoor,
One push WB, ATW and Manual.
If you select One push WB, the ONE PUSH
TRIGGER button is displayed. Click the button to
adjust the white balance instantly.
If you select Manual, the R Gain and B Gain controls
are displayed. Set 0 to 255 for each control.
Exposure mode
Select the exposure from among Full auto, Shutter
priority, Iris priority and Manual.
The setting items required for each setting appear.
Full auto: Adjusts the exposure automatically using the
electronic shutter, iris and gain. Select the Back light
compensation menu On or Off.
Shutter priority: Adjusts the exposure automatically
using the iris and gain. Select the electronic shutter
speed from the Shutter drop-down list.
Iris priority: Adjusts the exposure automatically using
the electronic shutter and gain. For the iris
adjustment, select the F number from the Iris drop-
down list.
Manual: Select the electronic shutter, iris and gain from
the drop-down list for each control.
Auto slow shutter
Select On to activate the auto slow shutter function, or
Off to deactivate it.
When On is selected, the exposure, including that for a
long time, is automatically adjusted according to the
brightness of the scene.
Back light compensation
Select On to activate the backlight compensation, or Off
to deactivate it.
Shutter
Select the electronic shutter speed from among the
following:
SNC-RZ30N:
1/10000, 1/6000, 1/4000, 1/3000, 1/2000, 1/1000,
1/725, 1/500, 1/350, 1/250, 1/180, 1/125, 1/100, 1/90,
1/60, 1/30, 1/15, 1/8, 1/4, 1/2, 1 (seconds).
SNC-RZ30P:
1/10000, 1/6000, 1/3500, 1/3000, 1/2500, 1/1750,
1/1000, 1/600, 1/420, 1/300, 1/215, 1/150, 1/120, 1/100,
1/75, 1/50, 1/25, 1/12, 1/6, 1/3, 1/2, 1 (seconds).
Iris
Select the iris (F number) from among the following:
F1.6, F2, F2.4, F2.8, F3.4, F4.0, F4.8, F5.6, F5.8, F8.0,
F9.6, F11, F14, F16, F19, F22, F28, Close.
Gain
Select the gain (dB) from among the following:
-3 dB, 0 dB, 2 dB, 4 dB, 6 dB, 8 dB, 10 dB, 12 dB, 14
dB, 16 dB, 18 dB, 20 dB, 22 dB, 24 dB, 26 dB, 28 dB
Note
When the shutter speed is set to 1 sec or 1/2 sec in the
Shutter priority or Manual mode, set the Focus mode
menu and the White balance mode menu to Manual.
Exposure compensation
When the Exposure mode menu is set to Full auto,
Shutter priority or Iris priority, select On to activate
the exposure compensation, or Off to deactivate it.
When it is set to On, select the EV value from among the
following:
+1.75, +1.5, +1.25, +1, +0.75, +0.5, +0.25, 0, –0.25, –
0.5, –0.75, –1, –1.25, –1.5, –1.75 (EV)
Saturation
Select the saturation in 7 steps, from –3 to 3.
Selecting 3 gives the image with the highest saturation.
Note
The Saturation setting is effective for the computer
image only. (It is not effective for the video signal
output.)
Sharpness
Select the sharpness in 16 steps, from 1 to 16.
Selecting 16 gives the image with the highest sharpness.
Contrast
Select the contrast in 7 steps, from –3 to 3.
Selecting 3 gives the image with the highest contrast.
Note
The Contrast setting is effective for the computer image
only. (It is not effective for the video signal output.)
Page 21
Setting the Camera — Camera setting Page
