Date time setting Section

Current date time
Displays the date and time set on the camera.
You can set the date and time using the following two
methods.
Note
When you purchased the camera, be sure to check the
date and time of the camera and set them if necessary.
System (PC) current date time
Displays the date and time set on your computer.
Click Apply to transfer the computer's date and time to
the camera.
The set date and time are shown on Current date time.
Manual current date time
When you want to set the camera's date and time
manually.
Select the lower 2-digits of the year, month, date, hour,
minutes and seconds from each drop-down list. Click
Apply to change the Current date time setting to the date
and time you selected.
Time zone selecting
Set the time difference from Greenwich Mean Time in
the area where the camera is installed. When you send
an E-mail, the senting date and time is adjusted
according to this setting.
Select the time zone where the camera is installed from
the drop-down list. Click Apply to change the Current
date time setting according to the selection.
Notes
• If the time zone selected on the Time zone selecting
menu is different from that set on the computer, the
time is adjusted using the time zone difference and set
on the camera.
18
Configuring the System — System setting Page
• Due to the network properties, there may be a slight
difference between the actual time and the time set on
the camera.
Date time format
Select the format of date and time to be displayed on the
monitor image from the drop-down list.
You can select from among yyyy-mm-dd hh:mm:ss
(year-month-day hour:minute:second), mm-dd-yyyy
hh:mm:ss (month-day-year hour:minute:second), and
dd-mm-yyyy hh:mm:ss (day-month-year
hour:minute:second).
Click Apply to transfer the setting to the camera.
Synchronization with NTP server
Synchronizes the camera's time with that of the NTP
(Network Time Protocol) server.
Select On to activate the time synchronization, and Off
to deactivate it.
NTP server name
Type the host name or IP address of the NTP server, up
to 64 characters.
This setting is valid when the Synchronization with NTP
server menu is set to On.
Interval time
Select the interval at which you want to adjust the
camera's time referring to the NTP server' time, between
1 and 24 hours. The set interval is a guide, and does not
indicate the exact time.
This setting is valid when the Synchronization with NTP
server menu is set to On.
Note
The time adjusted by this function may be slightly in
error depending on the network environments between
the camera and the NTP server.

Initialization Section

Backup setting
Saves the setting data of the camera in a file.
Click Save, and follow the instructions on the browser to
specify the folder and save the setting data of the
camera. The file name preset at the factory is "snc-
rz30.cfg."
