Before handling of the SIM card disconnect the router from power supply!
3. Power
The router requires an external DC power supply. The DC voltage required is between
+10 to +60 V DC. The router has built-in protection against reverse polarity without signaling.
Connect the power supply cable to the PWR connector on the front panel of the router (see
figure below).
4. Ethernet
An Ethernet cable may be connected to the ETH0 connector on the front panel (see figure
above). By default, this Ethernet port is configured as follows:
Connector Purpose
ETH0 LAN port (default)
Connect your laptop or PC to this port to
get a local web-server for device configu-
ration and diagnostics.
Default Setting
DHCP Server
IP Address: 192.168.1.1
NetMask: 255.255.255.0
18
QSG issued in CZ, January 25, 2017
