2. SIM card
The SIM card readers, for 3 V and 1.8 V SIM cards, are located on the rear panel of the
router. If you intend to use this device to communicate over a cellular network, please place
an activated data-provisioned SIM card with an unblocked PIN into the SIM card reader. Push
your SIM card into the SIM1 or SIM2 slot until it clicks in place.
Before handling of the SIM card disconnect the router from power supply!
3. Power
The router requires an external DC power supply. The DC voltage required is between
+10 to +60 V DC. The router has built-in protection against reverse polarity without signaling.
Connect the power supply cable to the PWR connector on the front panel of the router (see
figure below).
12
