Typical Application:
12VDC
IP camera
NetWay3012
(Mode "A / B")
NetWay3012
(Mode "A / B")
NVR/Network Server
12VDC
IP camera
12VDC
IP camera
NetWay1512
(Mode "B")
NetWay1512
(Mode "B")
I18W
NetWay1512
(Mode "B")
Video Monitor
NetWay1512 / NetWay3012 Installation Guide
