Setting


BACKLIGHT
CONTRAST
SHARPNESS
BRIGHTNESS
HUE
COLOR
COLOR TEMPERATURE
COLOR CONTROL
GAMMA CORRECTION
NATIVE
2.2
2.4
S GAMMA
DICOM SIM.
PROGRAMMABLE
MOVIE SETTINGS
NOISE REDUCTION
VIDEO1, VIDEO2, S-VIDEO inputs only
TELECINE
HDMI, DVD/HD, SCART, VIDEO1, VIDEO2,
S-VIDEO inputs only
ADAPTIVE CONTRAST
HDMI, DVD/HD, SCART, VIDEO1, VIDEO2,
S-VIDEO inputs only
PICTURE MODE
RESET

ADJUST

AUTO SETUP
VGA, RGB/HV inputs only
AUTO ADJUST
VGA, RGB/HV inputs only
H POSITION
All inputs except DVI, HDMI, DPORT
V POSITION
All inputs except DVI, HDMI, DPORT
CLOCK
VGA, RGB/HV inputs only
PHASE
VGA, RGB/HV, DVD/HD, SCART inputs only
*: depends on signal input
Adjusts the overall image and background brightness. Press + or - to adjust.
Note: When AMBIENT1 or AMBIENT2 is selected in picture mode, this function cannot be
changed.
Adjusts the image brightness in relationship to the input signal. Press + or - to adjust.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Adjusts the crispness of the image. Press + or - to adjust.
Adjusts the image brightness in relationship to the background. Press + or - to adjust.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Adjusts the hue of the screen. Press + or - to adjust.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Adjusts the color depth of the screen. Press + or - to adjust.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Adjusts the color temperature of the entire screen. A low color temperature will make the screen
reddish. A high color temperature will make the screen bluish. If TEMPERATURE needs further
adjustment, the individual R/G/B/ levels of the white point can be adjusted. To adjust the R/G/B
levels, CUSTOM must be showing as the COLOR TEMP selection.
Note: When sRGB is selected in picture mode, predefi ned 6500k is set so it cannot be changed.
When PROGRAMMABLE is selected in GAMMA CORRECTION, this function cannot be
changed.
Adjusts the hue of the Red, Yellow, Green, Cyan, Blue and Magenta.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Select a display gamma for best picture quality.
Note: When sRGB is selected in picture mode, this function cannot be changed.
Gamma correction is handled by the LCD panel.
Typical display gamma for use with a PC.
Good for video (DVD, etc.)
Special gamma for certain types of movies. Raises the dark parts and lowers the light parts of the
image (S-Curve).
DICOM GSDF curve simulated for LCD type.
A programmable gamma curve can be loaded using NEC optional software.
Adjusts the amount of noise reduction. Press + or - to adjust.
Automatically senses the sources frame rate for optimal picture quality.
Sets the level of adjustment for dynamic contrast.
Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [AMBIENT1] or
[AMBIENT2]. See page 18.
Resets the following settings within the PICTURE menu back to factory setting: BACKLIGHT,
CONTRAST, SHARPNESS, BRIGHTNESS, HUE, COLOR, COLOR TEMPERATURE,
COLOR CONTROL, GAMMA CORRECTION, MOVIE SETTINGS.
Automatically adjusts Screen Size, H position, V position, Clock, Phase and White Level.
H Position, V Position and Phase are adjusted automatically when new timing is detected.
Controls the horizontal position of the image within the Display area of the LCD.
Press + to move right. Press - to move left.
Controls the vertical position of the image within the Display area of the LCD.
Press + to move up. Press - to move down.
Press + to expand the width of the image on the right of the screen.
Press - to narrow the width of the image on the left.
Adjusts the visual "noise" on the image.
English-20
Default
70
50
50*
50
50
50*
10000K
0
NATIVE*
(except sRGB
setting)
0*
AUTO*
OFF
STANDARD
-
-
OFF
-
-
-
-
