TIME
Confi gures the time for the real-time clock.
DAYLIGHT SAVING
Confi gures daylight savings on or off.
RESET
Resets the following settings within the SCHEDULE menu back to factory setting: OFF TIMER,
SCHEDULE SETTINGS.

PIP

KEEP PIP MODE
Allows the monitor to remain in "PIP" and "TEXT TICKER" mode after powering off.
When Power is returned, PIP and TEXT TICKER appear without having to enter the OSD.
PIP MODE
Selects Picture-in-Picture mode.
OFF
Normal mode.
PIP
Picture in Picture mode.
POP
Picture out Picture mode.
PICTURE BY PICTURE-
Picture by picture (split screen) mode, with keep aspect.
ASPECT
PICTURE BY PICTURE-
Picture by picture (split screen) mode, with full screen.
FULL
PIP SIZE
Selects the size of the sub-picture used in Picture-in-Picture (PIP) mode.
SMALL
MIDDLE
LARGE
PIP POSITION
Determines where the PIP appears on the screen.
ASPECT
Selects sub picture aspect, [FULL], [NORMAL] and [WIDE]. See page 17.
TEXT TICKER
MODE
Enables Text Ticker and allows you to set Horizontal or Vertical direction.
POSITION
Selects the location of the Text Ticker on the screen.
SIZE
Determines the size of the Text Ticker in relationship to the overall screen size.
BLEND
Sets the transparency of the Text Ticker (0: transparent, 100: opaque).
DETECT
Enables auto-detection of the Text Ticker.
FADE IN
Enables fade-in of the text ticker.
SUB INPUT
Selects sub picture input signal.
RESET
Resets PIP options back to factory settings except ASPECT and SUB INPUT.

OSD

LANGUAGE
Select the language used by the OSD.
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
SVENSKA
РУССКИЙ
MENU DISPLAY TIME
Turns off the OSD after a period of inactivity. The preset choices are 10-240 seconds.
OSD POSITION
Determines the location where the OSD appears on the screen.
UP
DOWN
LEFT
RIGHT
English-22
-
OFF
-
OFF
OFF
LARGE
X = 95, Y = 92
FULL
OFF
Depends on
signal input
-
ENGLISH
(Depends on
destination)
30 Sec.
X = 128, Y = 225
