- Page 1 INSTALLATION & MAINTENANCE GUIDE Solar Landscape Lighting ® Solar LED Deck Light (White) ® ASDL-2014-P-WH Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Solar LED Deck Light (White) ® ASDL-2014-P-WH Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and in-...
- Page 3 Package Contents A. (1) Fixture Body C. (2) Screws B. (1) Mounting Bracket D. (2) Wall Anchors Product Dimensions 2.25” 3” 6.2” customersupport@amplighting.com • 813.978.3900 –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE Solar LED Deck Light (White) ® ASDL-2014-P-WH Test Solar Light Press the ON/OFF switch on the back of the fixture body. Place the solar light on a On/Off Switch non-abrasive surface with the solar panel against the surface to test the fixture.
- Page 5 INSTALLATION & MAINTENANCE GUIDE Solar LED Deck Light (White) ® ASDL-2014-P-BK Place Fixture Body on to Mounting Bracket Attach the bracket on the back of the luminaire to the mounting bracket on the wall. Mounting Bracket How to Replace Battery Remove the back cover Using a screwdriver, remove Screw...
- Page 6 INSTALLATION & MAINTENANCE GUIDE Solar LED Deck Light (White) ® ASDL-2014-P-WH Replace Battery Pack 1. Disconnect the quick connector. Quick Connector 2. Remove the battery pack out of the solar panel box and replace it with a new one. 3. Connect the quick connector to the new battery pack.
- Page 7 customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Specifications and product details subject to change without notice. © Copyright 2021, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASDL-2014-P-WH-ver3.pdf...
