- Page 1 INSTALLATION & MAINTENANCE GUIDE Solar Landscape Lighting ® Sol Box ® ASDL-2014-P-BK Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Sol Box ® ASDL-2014-P-BK Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and in- structions may result in serious injury, property damage and void the warran- These instructions do not intend to cover all variations in installation, opera- tion maintenance or mounting situations.
- Page 3 Package Contents A. (1) Fixture Body C. (2) Screws B. (1) Mounting Bracket D. (2) Wall Anchors Product Dimensions 2.25” 3” 6.2” customersupport@amplighting.com • 813.978.3900 –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE Sol Box ® ASDL-2014-P-BK Test Solar Light Press the ON/OFF switch on the back of the fixture body. Place the solar light on a On/Off Switch non-abrasive surface with the solar panel against the surface to test the fixture. There will be a short delay Fixture Body for the fixture to light up.
- Page 5 INSTALLATION & MAINTENANCE GUIDE Sol Box ® ASDL-2014-P-BK Place Fixture Body on to Mounting Bracket Attach the bracket on the back of the luminaire to the mounting bracket on the wall. Mounting Bracket How to Replace Battery Remove the back cover Using a screwdriver, remove Screw screws from the fixture body.
- Page 6 INSTALLATION & MAINTENANCE GUIDE Sol Box ® ASDL-2014-P-BK Replace Battery Pack 1. Disconnect the quick connector. Quick Connector 2. Remove the battery pack out of the solar panel box and replace it with a new one. 3. Connect the quick connector to the new battery pack.
- Page 7 customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2020, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASDL-2014-P-BK-ver2.pdf...
