- Page 1 INSTALLATION & MAINTENANCE GUIDE Solar Landscape Lighting ® Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and in-... -
Page 3: Product Dimensions
Package Contents E. (32) Bulbs (2 replacement A. (1) Solar Panel bulbs are included) B. (1) Support Arm F. (1) Stake C. (1) Clamp with Support Arm G. (4) Straps D. (1) Bistro String (50 feet H. (4) Screws long) I. - Page 4 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Follow 1 of the 4 Solar Panel Mounting Methods Method 1: Clamp Mount Mount Clamp with Support Arm Support Arm Clamp Clamp Mounting Surface Mounting Surface Attach the clamp onto the side of the mounting surface.
- Page 5 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Method 2: Surface Mount Surface Mount Mark Place the support arm onto the surface and mark points using Wall Anchor the holes as a guide. Then, drill Screw proper holes for the wall anchors to be inserted.
- Page 6 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Method 3: Strap Mount Insert Straps Strap Pass the ends of the strap through two holes on the support arm. Support Arm Tie the Strap Install the support arm by...
- Page 7 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Method 4: Stake Mount Install Stake to Support Arm Insert the top end of the stake into the base of support arm. Support Arm Stake Insert Stake to Ground Insert the stake into the ground.
-
Page 8: Connect Wires
INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Install Solar Panel and Bistro String Remove Wire Cover Twist and remove the wire cover from the solar panel. Solar Panel Wire Wire Cover Connect Wires Connect the wire from bistro string to the wire from the solar panel. - Page 9 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Test Solar Panel Place the solar panel onto a flat FLAT SURFACE opaque working surface. Press the ON/OFF switch on the back of the solar panel to test the light source.
-
Page 10: Final Adjustment
INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK Install Remaining Bulbs Thread bulbs onto the sockets and tighten gently. Socket Bulb Final Adjustment Loosen the screw at the knuckle ROTATE to adjust the solar panel to make sure it can get plenty of sunlight. - Page 11 INSTALLATION & MAINTENANCE GUIDE Solar Bistro Lights (50ft) ® ASSI-9008-50-BK How to Replace Battery 1. Using a screwdriver, remove Screw the screws from the cover on Cover the back of the solar panel. 2. Remove the cover. Battery 3. Remove the battery out of...
- Page 12 Specifications and product details subject to change without notice. © Copyright 2021, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASSI-9008-50-BK-ver1.pdf...
