- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® MR16 HydraPro™ In-Grade Light (Lamp Ready) ® AWL-703-25-BBZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE MR16 HydraPro™ In-Grade Light (Lamp Ready) ® AWL-703-25-BBZ Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture B. (1) Stake Parts Required (sold separately) A. (1) MR16 Product Dimensions 4” 4.25” customersupport@amplighting.com • 813.978.3900 –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE MR16 HydraPro™ In-Grade Light (Lamp Ready) ® AWL-703-25-BBZ Removing the Faceplate Unlock the screws and remove the Screw faceplate, gasket, and lens from the Faceplate housing. Gasket Lens Housing Install/Replace Bulb Insert the bulb with the correct...
- Page 5 Install Lens and Faceplate Screw Place the lens, gasket, and faceplate back onto the housing. Secure them with the screws previously removed. Hand tighten Faceplate until snug, then use a srewdriver to secure them in a star pattern. Gasket Lens Housing Install Stake Board...
- Page 6 INSTALLATION & MAINTENANCE GUIDE MR16 HydraPro™ In-Grade Light (Lamp Ready) ® AWL-703-25-BBZ Install Fixture to Stake Clear away an area in the ground at the Wireway Slot wireway slot on top of the stake. Lay Fixture the luminaire pigtail into the wireway...
- Page 7 Install/Replace Glare Guard Remove Ring Loosen the screws and remove the Screw faceplate from the housing. Faceplate Housing Install Glare Guard Attach the glare guard onto the Screw housing and secure with the screws previously removed. Glare Guard Housing customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m is-AWL-703-BBZ-ver5.pdf...
