- Page 1 INSTALLATION & MAINTENANCE GUIDE Solar Landscape Lighting ® Sol Box Brass ® ASDL-2014-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE Sol Box Brass ® ASDL-2014-B-BZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and in- structions may result in serious injury, property damage and void the warran- These instructions do not intend to cover all variations in installation, opera- tion maintenance or mounting situations. - Page 3 Package Contents A. (1) Fixture Body D. (2) Mounting Brackets B. (1) Solar Panel Box E. (4) Screws C. (1) Cover Plate F. (4) Wall Anchors Product Dimensions 2.25” 3” 4.2” LUMINAIRE 2.25” 3” 2.2” SOLAR PANEL BOX customersupport@amplighting.com • 813.978.3900 –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE Sol Box ® ASDL-2014-B-BZ Test Solar Light Press the ON/OFF switch on the back of the fixture body. Place the solar light on a On/Off Switch non-abrasive surface with the solar panel against the surface to test the fixture. There will be a short delay Fixture Body for the fixture to light up.
-
Page 5: Installation Optional
INSTALLATION & MAINTENANCE GUIDE Sol Box Brass ® ASDL-2014-B-BZ INSTALLATION OPTIONAL 1 Install Mounting Bracket 1. Place the mounting bracket onto Hole the desired location and mark two points on the wall for the wall Wall Anchor anchors. Mounting 2. Remove the mounting bracket. Drill Bracket the proper holes on the marks for the wall anchors by using an elec-... -
Page 6: Install Mounting Bracket
INSTALLATION & MAINTENANCE GUIDE Sol Box Brass ® ASDL-2014-B-BZ INSTALLATION OPTIONAL 2 If the luminaire is going to be installed in a location where there is low sunlight, make sure it is still close to an area where there is plenty of sunlight for the solar panel to be installed separately. - Page 7 Remove Solar Panel Box from Fixture Body Solar Panel Box Fixture Body Slide the solar panel box off the top of the fixture body to remove it. Disconnect Quick Connector Disconnect the quick connector to Female connector separate the male connector from female connector.
- Page 8 INSTALLATION & MAINTENANCE GUIDE Sol Box Brass ® ASDL-2014-B-BZ Install Fixture Body onto Mounting Bracket Pass the female connector and wire through the hole. Place Mounting the bracket on the back of the fixture body onto the mounting Bracket bracket. Wire Fixture Body Female connector...
- Page 9 Install Solar Panel Box on to Mounting Bracket Solar Panel Box Carefully tuck the quick connector and wire inside of the hole. Place the bracket of the solar panel box Mounting onto the mounting bracket. Bracket Wire Quick connector Hole customersupport@amplighting.com •...
- Page 10 INSTALLATION & MAINTENANCE GUIDE Sol Box Brass ® ASDL-2014-B-BZ Install Solar Panel Box on to Mounting Bracket Quick Connector Solar Panel Box Screw Cover Battery Pack 1. Using a screwdriver, remove the screws from the cover of the solar panel box. 2.
- Page 11 customersupport@amplighting.com • 813.978.3900 –11–...
- Page 12 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2020, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASDL-2014-B-BZ-ver3.pdf...
