The procedures to set the output priority mode are as follows.
1. Press [Shift]+[V-set](Config） to enter into the configuration menu
2. Use knob or left and right keys to select Mode, press [Enter] to confirm.
3. Select CC Priority or CV Priority, press [Enter] to enter into the setting
4. Select the desired menu item, press [Enter] to confirm.
5. Use knob to adjust the values and press [Enter] to confirm.

4.1.2 Set the Output-On/Output-Off Delay Time

You can set the output-on/output-off delay time within the range from 0 seconds
to 10 seconds. During the output delay time, the VFD displays
right corner. Once the output-on delay timer expires, the VFD displays "CC" or
"CV". Once the output-off delay timer expires, the VFD displays "OFF".
•
•
The procedures to set the output delay time are as follows.
1. Press [Shift]+[V-set](Config) to enter into the configuration menu interface.
2. Use knob or left and right keys to select On Delay or Off Delay and press
3. Use knob to adjust the output-on/output-off delay time and press [Enter] to

4.1.3 Set the Sense Function State

This menu item is used to switch the power supply to local sensing or remote
sensing.
IT-M3100D series power supplies support two connection methods between
power supply and device under test (DUT): Local sensing and Remote sensing.
The remote sensing is used for maximizing measurement accuracy. (Refer to
2.6 Connecting the Device Under Test (DUT)
Current priority mode keeps the output current constant. In current priority
mode, the output current should be set to the desired value. The output is
controlled by a constant-current feedback loop, which maintains the output
current at its programmed setting.
interface.
interface.
•
Select CV Priority, the menu displays V-Rise Time and V-Fall Time.
•
Select CC Priority, the menu displays I-Rise Time and I-Fall Time.
On Delay is from the time that a command to turn on the output is received
until the output actually turns on.
Off Delay is from the time that a command to turn off the output is received
until the output actually turns off.
[Enter] to confirm.
confirm.
Copyright © Itech Electronic Co., Ltd.
Functions and Features
for more information.)
on the top
