RS–232 Configuration
The user needs to configure the RS–232 interface parameters in the system
menu before using the remote control. The RS–232 interface parameters are as
follows.
Name
Baud rate
Data Bit
parity bit
stop bit
The operation steps are as follows.
1. Press [Shift]+[Display] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Comm and press [Enter]
3. Use left and right keys or rotate the knob to select RS232 and press [Enter]
4. Rotate the knob to set the baud rate.
5. After finishing the setting, press [Esc] to exit.
RS-232 Troubleshooting
If you meet some problems when communicating with PC by RS-232 interface,
please check the following items:
Description
Select the baud rate from the following options: 4800,
9600, 19200, 38400, 57600, 115200
8 (fixed)
None (fixed)
1 (fixed)
key to confirm.
key to confirm.
RS232
9600_8_None_1
