1.

Introduction

1.1

Features


Atmel SAMDA1J16A microcontroller

Embedded debugger (EDBG)
USB interface
o
Programming and debugging on board SAMDA1J16A through Serial Wire Debug (SWD)
o
Virtual COM-port interface to target via UART
o
Atmel Data Gateway Interface (DGI) to target via SPI and TWI
o
Four GPIOs connected to target for code instrumentation
o

Digital I/O
Two mechanical buttons (user and reset button)
o
One user LED
o
Three extension headers
o

Four possible power sources

External power (3.3/5V)

External power (12V)

Embedded debugger USB (5V)

Target USB (5V)

32kHz crystal

USB interface, device and reduced host mode

On-board LIN Transceiver as System-Base Chip (SBC)

LIN Slave/Master configurable

Intregrated VREG regulates external LIN_VS (12V) to 3.3V
1.2

Kit Overview

The SAMDA1 Xplained Pro evaluation kit is a hardware platform to evaluate the Atmel SAMDA1J16A.
The kit offers a set of features that enables the user to get started using SAMDA1J16A peripherals right away and to get an
understanding of how to integrate the device in their own design.
